                                    132CABLE MANAGEMENTTogether we GENERATE VALUECantilever Arms Base Plates Cone Point ScrewSuspension UnitPurlin ClipPVC End CapsChannel ConnectorsStand Off BracketsPart No. DescriptionMP521 150mm Cantilever ArmMP522 300mm Cantilever ArmMP523 450mm Cantilever ArmMP524 600mm Cantilever ArmMP525 750mm Cantilever ArmMP526 900mm Cantilever ArmMP527 1000mm Cantilever Arm Part No. DescriptionMP33 Single Lug Channel Base PlateMP34 Dougle Lug Channel Base PlateMP35 Double Channel Base PlateMP36 Single Channel Gusset Base PlateMP37 Double Channel Gusset Base PlatePart No. DescriptionCP1040 M10 x 40mm Cone Point ScrewPart No. DescriptionMP46 Suspension UnitPart No. DescriptionMP45 Purlin ClipPart No. DescriptionMP50/W 41x41mm White PVC End CapMP50/B 41x41mm Black PVC End CapMP51/W 41x21mm White PVC End CapMP51/B 41x21mm Black PVC End CapPart No. DescriptionMP47/21 21mm Internal Channel ConnectorMP47/41 41mm Internal Channel ConnectorMP48/21 21mm External Channel ConnectorMP48/41 41mm External Channel ConnectorPart No. DescriptionTHB50 50mm Stand Off BracketTHB75 75mm Stand Off BracketTHB100 100mm Stand Off BracketTHB150 150mm Stand Off BracketTHB225 225mm Stand Off BracketTHB300 300mm Stand Off Bracket• Compliant to BS6946• Authorised for use on London Underground• Compliant to BS6946• Authorised for use on London Underground• Manufactured from Grade 8.8 High Tensile steel• Compliant to BS6946• Authorised for use on London Underground• Captive nut dramatically reduces installation time and slides along bracket length, allowing easy adjustment of fixing point location• Suitable for installations of light, medium and heavy duty cable tray and basketMP33 MP34MP35MP36 MP37MP47/21 MP48/21MP47/41 MP48/41Channel Support and Accessories
