184CABLE MANAGEMENTTogether we GENERATE VALUECable TrunkingQuickFix Trunking%u2022 Up to 6x faster installation%u2022 IP4X compliant as standard%u2022 Lengths are supplied with coupler, cover strap and Unibolts. Please note cover straps are only required for Length to Length assembly and not for Fitting to Length assemblyPart No. Size (mm)TK22 50x50TK33 75x75TK42 100x50TK44 100x100TK66 150x150Gusset Bend Outside Lid Gussett Bend Top LidPart No. W (mm) H (mm) X (mm)GOB22 50 50 25GOB33 75 75 25GOB42 100 50 25GOB44 100 100 25GOB66 150 150 25Part No. W (mm) H (mm) X (mm)GTB22 50 50 91GTB33 75 75 115GTB42 100 50 140GTB44 100 100 140GTB66 150 150 193Intersection Box Blank EndPart No. W (mm) H (mm) X (mm)ITB22 50 50 25ITB33 75 75 25ITB42 100 50 25ITB44 100 100 25ITB66 150 150 25Part No. W (mm) H (mm)BE22 50 50BE33 75 75BE42 100 50BE44 100 100BE66 150 150Gussett Tee Top Lid Gussett Bend Inside LidPart No. W (mm) H (mm) X (mm) Y (mm)GTT22 50 50 25 129GTT33 75 75 25 154GTT42 100 50 25 180GTT44 100 100 25 180GTT66 150 150 25 230Part No. W (mm) H (mm) X (mm)GIB22 50 50 25GIB33 75 75 25GIB42 100 50 25GIB44 100 100 25GIB66 150 150 25Full fittings and accessories range available
