420HEATING & VENTILATIONTogether we GENERATE VALUEairflowDomestic Ventilation%u2022 Axial Fan%u2022 Awarded Quiet Mark by Noise Abatement Society%u2022 Two speed options available%u2022 To fit duct diameters 100mm (QT100)/125mm (QT125) / 150mm (QT150)%u2022 IP45 Rating%u2022 Wall or ceiling mounted%u2022 Automatic %u2018room refresh%u2019 option (with T model)%u2022 QT100 available in blackPart No. Description Flow Rate (l/sec)Sound Pressure dB(A)Power Consumption (W)Dimensions (H x W x D mm)9041259 QuietAir 100B - Basic 21 / 25 25 / 30 5 / 9 147 x 147 x 13190002185 QuietAir 100 Black Edition B 21 / 25 25 / 30 5 / 9 147 x 147 x 1319041260 QuietAir 100T - Timer 21 / 25 25 / 30 5 / 9 147 x 147 x 13190002186 QuietAir 100 Black Edition T 21 / 25 25 / 30 5 / 9 147 x 147 x 1319041261 QuietAir 100HT - Humidity Timer 21 / 25 25 / 30 5 / 9 147 x 147 x 13190002187 QuietAir 100 Black Edition HT 21 / 25 25 / 30 5 / 9 147 x 147 x 1319041262 QuietAir 100MST - Motion Sensor Timer 21 / 25 25 / 30 5 / 9 147 x 147 x 13190002188 QuietAir 100 Black Edition MST 21 / 25 25 / 30 5 / 9 147 x 147 x 1319041497 QuietAir 120B - Basic 42 / 47 32 / 36 10 / 13 176 x 176 x 1559041498 QuietAir 120T - Timer 42 / 47 32 / 36 10 / 13 176 x 176 x 1559041499 QuietAir 120HT - Humidity Timer 42 / 47 32 / 36 10 / 13 176 x 176 x 1559041500 QuietAir 120MST - Motion Sensor Timer 42 / 47 32 / 36 10 / 13 176 x 176 x 15590000454 QuietAir 150B - Basic 61 / 72 35 / 39 6 / 10 210 x 210 x 19090000455 QuietAir 150T - Timer 61 / 72 35 / 39 6 / 10 210 x 210 x 19090000456 QuietAir 150HT - Humidity Timer 61 / 72 35 / 39 6 / 10 210 x 210 x 19090000458 QuietAir 150VS - Variable Speed 13 / 72 35 / 39 6 / 10 210 x 210 x 190QuietAirPart No. Description Flow Rate (l/sec)Sound Pressure dB(A)Power Consumption (W)Dimensions (H x W x D mm)72684305 LOOVENT eco 230V Timer 17 / 31 29 / 47 3.6 / 12 167 x 187 x 13872684306 LOOVENT eco 230V Humidity Timer 17 / 31 29 / 47 3.6 / 12 167 x 187 x 13872684307 LOOVENT eco 230V Motion Sensor Timer 17 / 31 29 / 47 3.6 / 12 167 x 187 x 13872684309 LOOVENT eco 12V SELV Timer 17 / 31 29 / 47 3.6 / 12 167 x 187 x 13872684310 LOOVENT eco 12V SELV Humidity Timer 17 / 31 29 / 47 3.6 / 12 167 x 187 x 13872684308 LOOVENT eco 230V dMEV Timer 7/15 / 9/15 / 16/31 25/46 / 25/46 / 28/46 2.8/8.9 / 3/8.9 / 2.8/12 167 x 187 x 13872684311 LOOVENT eco 230V dMEV Humidity Timer 7/15 / 9/15 / 16/31 25/46 / 25/46 / 28/46 2.8/8.9 / 3/8.9 / 2.8/12 167 x 187 x 13872684312 LOOVENT eco 12V SELV dMEV Timer 7/15 / 9/15 / 16/31 25/46 / 25/46 / 28/46 2.8/8.9 / 3/8.9 / 2.8/12 167 x 187 x 13872684313 LOOVENT eco 12V SELV dMEV Humidity Timer 7/15 / 9/15 / 16/31 25/46 / 25/46 / 28/46 2.8/8.9 / 3/8.9 / 2.8/12 167 x 187 x 138LOOVENT ecoDesigned and engineered in Germany, every detail of the QuietAir range has been constructed to produce high efficiency, low energy and ultra-low noise levels.%u2022 Centrifugal fan for toilets, kitchens and bathrooms%u2022 Smallest 30 l/sec fan in its class%u2022 Ideal replacement for old Loovents%u2022 Can be recessed and surface mount in both portrait and landscape%u2022 To fit duct diameter 100 mm%u2022 Powerful low energy, 2-speed fan%u2022 Available as intermittent and dMEV fan (both in 230V and 12V SELV version)%u2022 IPX5 rated (possible installation in zone 1)The LOOVENT eco range is a powerful discreetly styled Centrifugal fan. It is modular in design for ease of installation and maintenance ensuring effective ventilation with minimal noise and maximum efficiency.iCONstant%u2022 Suitable for all rooms%u2022 Guaranteed constant volume feature (smart flow sensor)%u2022 IPX5 rated (possible installation in zone 1)%u2022 To fit duct diameter 100 mm%u2022 LED self-diagnostics and %u201cfine tune%u201d commissioning option of flow rate%u2022 iCONstant flex models are recognised in SAP PCDBiCONstant is one of the quietest continuous extract fan on the market. Also known as a decentralised Mechanical Extract Ventilation (dMEV) fan, iCONstant is designed to be extremely economical to run and costs less than a lightbulb to run for a year.Part No. Description Flow Rate (l/sec)Sound Pressure dB(A)Power Consumption (W) Dimensions (HxWxD mm)72687117 iCONstant - Timer 6/8 / 8/13 / 13/20 10/15 / 15/28 / 28/38 1.1/1.2 / 1.2/1.7 / 1.7/2.9 197 x 197 x 12072687118 iCONstant - Humidity Timer 6/8 / 8/13 / 13/20 10/15 / 15/28 / 28/38 1.1/1.2 / 1.2/1.7 / 1.7/2.9 197 x 197 x 12072687119 iCONstant flex - Timer 5/8 8/11 1 /13 13/16 16/20 15.4/21.6 21.6/26.8 26.8/31.0 31.0/32.6 32.6/39.9 1.26/1.51 1.51/1.79 1.79/1.96 1.96/2.54 2.54/4.42 197 x 197 x 12072687120 iCONstant flex - Humidity Timer 5/8 8/11 11/13 13/16 16/20 15.4/21.6 21.6/26.8 26.8/31.0 31.0/32.6 32.6/39.9 1.26/1.51 1.51/1.79 1.79/1.96 1.96/2.54 2.54/4.42 197 x 197 x 120
