P. 52

                    CABLE & ACCESSORIES
Terminals, Glands & Tape
 Pre-Insulated Terminals
Copper Terminals and Splices
    More sizes and terminals available
• Material: Copper
• Insulation: Polyvinyl
Chloride
• UL Approval E100455
• CSA Approval 093995
600 Volts
• Up to 75C
• RoHS Compliant
Part No.
Description
0.5-1.5mm Ring Terminal 5.3 Stud 1.5-2.5mm Ring Terminal 5.3 Stud 2.5-6mm Ring Terminal 6.5 Stud 0.5-1.5mm Fork Terminal 4.3 Stud 1.5-2.5mm Fork Terminal 5.3 Stud 2.5-6mm Fork Terminal 5.3 Stud 0.5-1.5mm Pin Terminal 12mm 1.5-2.5mm Pin Terminal 12mm 2.5-6mm Pin Terminal 14mm 0.5-1.5mm Female Push On Terminal 6.3mm 1.5-2.5mm Female Push On Terminal 6.3mm 2.5-6mm Female Push On Terminal 6.3mm 0.5-1.5mm Male Push On Terminal 6.3mm 1.5-2.5mm Male Push On Terminal 6.3mm 2.5-6mm Male Push On Terminal 6.3mm 0.5-1.5mm Blade Terminal 18mm 1.5-2.5mm Blade Terminal 18mm 2.5-6mm Blade Terminal 18mm 0.5-1.5mm Insulated Butt Splice 1.5-2.5mm Insulated Butt Splice 2.5-6mm Insulated Butt Splice
More sizes available
• Conforms to BS61238 Class A
• Electro-tin plated
• Up to 1000 volts
• Lugs are bell mouth entry
Part No.
10-6TQ 10-8TQ 16-6TQ 16-8TQ 16-10TQ 25-8TQ 25-10TQ 35-8TQ 35-10TQ 50-8TQ 50-10TQ 70-10TQ 70-12TQ 95-10TQ 10BS 16BS 25BS 35BS 50BS 70BS 95BS
Lugs
Description
       53RER
 53BER
 65YER
 43RF
 53BF
 53YF
 12RP
 12BP
 14YP
 63RFP
 63BFP
 63YFP
 63RMP
 63BMP
 63YMP
 18RB
 18BB
 18YB
 15BSL
 25BSL
 6BSL
    10mm with 6mm Stud
 10mm with 8mm Stud
 16mm with 6mm Stud
 16mm with 8mm Stud
 16mm with 10mm Stud
 25mm with 8mm Stud
 25mm with 10mm Stud
 35mm with 8mm Stud
 35mm with 10mm Stud
 50mm with 8mm Stud
 50mm with 10mm Stud
 70mm with 10mm Stud
 70mm with 12mm Stud
 95mm with 10mm Stud
 10mm Butt Splice
 16mm Butt Splice
 25mm Butt Splice
 35mm Butt Splice
 50mm Butt Splice
 70mm Butt Splice
 95mm Butt Splice
                                               Nylon Cable Glands
Polyamide Cable Gland, VDE Approved
• Includes washer and Locknut
• Temperature -30C to 150C Intermittant
• Black, Red, Grey, Dark Grey and Blue Available
• IP68
• Simple & easy to install
Part No.
Underground Warning Tape
    Description
16mm Gland 5-10 Diameter 20mm Gland 6-12 Diameter 20mm Gland 10-14 Diameter 25mm Gland 13-18 Diameter 32mm Gland 18-25 Diameter
Part No.
UMT-EL UMT-STL
Description
GENERATE VALUE
150mm Width 365m Length
     CG/LNM-16
 CG/LNM-20S
 CG/LNM-20L
 CG/LNM-25
 CG/LNM-32
         Electrical Cable Below
 Street Lighting Cable Below
      52
