                                    595LIGHTINGTogether we GENERATE VALUELED PanelsPart No. DescriptionBR1114 32W 4000K LED Panel TPb 600x600BR1115 32W 6000K LED Panel TPb 600x600BR1124 45W 4000K LED Panel TPb 1200x600BR1125 45W 6000K LED Panel TPb 1200x600BR1129 LED Panel 3Hr Emergency Pack• LED backlit panel solution for a range of commercial applications• Slim profile, white aluminium frame with high quality TP(b) diffuser, providing low glare (UGR<21)• Compatible with Brackenheath’s plug in, self-test emergency pack• Loop in, loop out terminals provide for an easier and more economical installation• Suitable for suspended ceilings; surface and suspension mounting kits available• IP20 rating, suitable for indoor use• 5-year guarantee• BS EN 60598-1LED Panels Emergency PackPart No. DescriptionBR1129 Panel Remote 3Hr Emergency Pack• Plug-and-play emergency self-test pack for Brackenheath LED panel range• 3W output power, 12-60V, 2.5Ah Ni-CD/Ni-MH battery with 12V-60V output• 3 hours emergency duration• Includes a trailing LED indicator for positioning alongside panel• Size: 200x100x33mm• Weight: 800g• 2-year guarantee• BS EN 61347-2AccessoriesPart No. DescriptionBR1131 Panel 6 Wire Suspension KitBR1130 Panel Surface Mount Kit 600x600BR1132 Panel Surface Mount Kit 600x1200• 5-year guaranteeTp(B) Backlit PanelsPart No. DescriptionBR1251 6W CCT3 LED Round Panel TPb 120BR1252 9W CCT3 LED Round Panel TPb 150BR1253 12W CCT3 LED Round Panel TPb 170BR1254 18W CCT3 LED Round Panel TPb 220• LED Edgelit panel solution for a range of commercial applications• Slim profile, white aluminium frame with high quality TP(b) diffuser, providing low glare (UGR<21)• Compatible with Brackenheath’s plug in, selftest emergency pack• Loop in, loop out terminals provide for an easier and more economical installation• Suitable for recessed mounting• IP20 rating, suitable for indoor use• Colour temperature 3000K/4000K/6000K• 5-year guarantee• BS EN 60598-1CCT3 Circular PanelsLED CCT3 Round PanelsPart No. DescriptionBR1113 32W CCT3 LED Panel TPb 600x600BR1123 50W CCT3 LED Panel TPb 1200x600BR1129 LED Panel CCT3 3Hr Self-Test EM PackBR1196 60W DALI Dimmable DriverLED CCT3 PanelsCommercial DownlightsPart No. DescriptionBR2001 15W CCT3 IP44 Downlight WHBR2002 18W CCT3 IP44 Downlight WH• Ceiling downlight for commercial applications• 15W, 1500lm, 18W 1800lm, CCT3 Selectable 3000K, 4000K, and 6000K (Warm white, Cool White, Daylight), 100° Beam Angle, CRI>80, IP44, 220-240V• UGR<22 in compliance with BS EN 12464-1• Flicker free LED ENEC Approved Driver• Raised retaining springs allow for installation in ceiling tiles up to 40mm deep• Plug in emergency pack option available • Easy switching between three colour 3000K/4000K/6000K temperatures with switch located at the rear• IP44 rating for protection from solid objects larger than 1mm and splashes of water from any direction• 5-year guarantee
