Page 610 - Fegime - Electrical Product Guide Issue 1 V5
P. 610

                    LIGHTING
Energy Efficient LED Bulkheads
Alleycat Round LED
• Robust and vandal proof LED
• IP65 – rubber gasket protects against dust and water
• Robust die-cast aluminium body in black or white
• Clear or opal polycarbonate diffuser
• Available with all standard light management options
    Part No. Description Base Colour Dimensions Power
  FHBL9965-160-W-OP
 Round 1300 Lumen White Opal
 White
 Ø300 x 118mm
 13W
 FHBL9965-160-W-OP-EM
 Round 1300 Lumen White Opal Em
 White
 Ø300 x 118mm
 13W
 FHBL9965-160-W-OP-MS
 Round 1300 Lumen White Opal Ms
 White
 Ø300 x 118mm
 13W
 FHBL9965-160-W-OP-EM-MS
  Round 1300 Lumen White Opal Em Ms
  White
  Ø300 x 118mm
  13W
 FHBL9965-210-W-OP
Round 1900 Lumen White Opal
White
Ø300 x 118mm
19W
 FHBL9965-210-W-OP-EM
 Round 1900 Lumen White Opal Em
 White
 Ø300 x 118mm
 19W
 FHBL9965-210-W-OP-MS
  Round 1900 Lumen White Opal Ms
  White
  Ø300 x 118mm
  19W
 FHBL9965-210-W-OP-EM-MS
 Round 1900 Lumen White Opal Em Ms
 White
 Ø300 x 118mm
 19W
    EM=Emergency / MS=Microwave Sensor / BL=Back Lit
Alleycat Square LED
Ideal for harsh environments.
• Robust die-cast aluminium body in black or white
• Clear or opal polycarbonate diffuser
• Hinged LED gear tray and Time-in-a-Box packaging for swift and
easy installation
• BESA box fixing points for easy cable entry
   Part No.
Description
Base Colour
Dimensions
Power
 FHBL9065-160-W-OP
 Square 1300 Lumen White Opal
 White
 246 x 246 x 103mm
 13W
 FHBL9065-160-W-OP-EM
 Square 1300 Lumen White Opal Em
 White
 246 x 246 x 103mm
 13W
 FHBL9065-160-W-CL
 Square 1800 Lumen White Clear
 White
 246 x 246 x 103mm
 13W
 FHBL9065-160-W-CL-EM
  Square 1800 Lumen White Clear Em
  White
  246 x 246 x 103mm
  13W
 FHBL9065-160-B-OP
Square 1300 Lumen Black Opal
Black
246 x 246 x 103mm
13W
 FHBL9065-160-B-OP-EM
 Square 1300 Lumen Black Opal Em
 Black
 246 x 246 x 103mm
 13W
 FHBL9065-160-B-CL
 Square 1800 Lumen Black Clear
 Black
 246 x 246 x 103mm
 13W
 FHBL9065-160-B-CL-EM
  Square 1800 Lumen Black Clear Em
  Black
  246 x 246 x 103mm
  13W
 FHBL9065-160-W-OP-MS
Square 1300 Lumen White Opal Bl Ms
White
246 x 246 x 103mm
13W
 FHBL9065-210-W-OP-MS
 Square 1900 Lumen White Opal Bl Ms
 White
 246 x 246 x 103mm
 19W
 FHBL9065-160-W-OP-EM-MS
 Square 1300 Lumen White Opal Bl Em Ms
 White
 246 x 246 x 103mm
 13W
 FHBL9065-210-W-OP-EM-MS
  Square 1900 Lumen White Opal Bl Em Ms
  White
  246 x 246 x 103mm
  19W
 FHBL9065-160-W-CL-MS
Square 1800 Lumen White Clear Ms
White
246 x 246 x 103mm
13W
 FHBL9065-210-W-CL-MS
 Square 2500 Lumen White Clear Bl Ms
 White
 246 x 246 x 103mm
 19W
 FHBL9065-160-W-CL-EM-MS
 Square 1800 Lumen White Clear Bl Em Ms
 White
 246 x 246 x 103mm
 13W
 FHBL9065-210-W-CL-EM-MS
  Square 2500 Lumen White Clear Em Ms
  White
  246 x 246 x 103mm
  19W
 FHBL9065-160-B-OP-MS
Square 1300 Lumen Black Opal Bl Ms
Black
246 x 246 x 103mm
13W
 FHBL9065-210-B-OP-MS
 Square 1900 Lumen Black Opal Bl Ms
 Black
 246 x 246 x 103mm
 19W
 FHBL9065-160-B-OP-EM-MS
 Square 1300 Lumen Black Opal Bl Em Ms
 Black
 246 x 246 x 103mm
 13W
 FHBL9065-210-B-OP-EM-MS
  Square 1900 Lumen Black Opal Bl Em Ms
  Black
  246 x 246 x 103mm
  19W
 FHBL9065-160-B-CL-MS
Square 1800 Lumen Black Clear Ms
Black
246 x 246 x 103mm
13W
 FHBL9065-210-B-CL-MS
 Square 2500 Lumen Black Clear Bl Ms
 Black
 246 x 246 x 103mm
 19W
 FHBL9065-160-B-CL-EM-MS
  Square 1800 Lumen Black Clear Em Ms
  Black
  246 x 246 x 103mm
  13W
 FHBL9065-210-B-CL-EM-MS
 Square 2500 Lumen Black Clear Bl Em Ms
 Black
 246 x 246 x 103mm
 19W
      EM=Emergency / MS=Microwave Sensor / BL=Back Lit
