                    LIGHTING
Track Systems
1-Circuit 230V Track System
16A Mains voltage track, connector & accessory system. Ideal for applications where spotlights may need to be frequently added or removed.
• 1-Circuit 230V track features metal to metal connections to optimise earthing
• 1-Circuit 230V track is rated at 16A, giving a maximum lamp load of 3800W
per track circuit (e.g. 76 x 50W spotlights)
• 1-Circuit 230V track does not come with a Live End.
Live Ends must be ordered separately
• Figure of ‘8’ patterns cannot be constructed using this system
• Live end, dead end and connector dimensions refer to length after insertion
into track
1-Circuit 230V Track
Dimensions (mm)
       Part No.
Description
Colour/ Finish
Length
 T4-WH
 1-Circuit Track, 230V, inc Dead End
 White
 4ft / 1115mm
 T4-BL
  1-Circuit Track, 230V, inc Dead End
  Black
  4ft / 1115mm
 T4-SG
1-Circuit Track, 230V, inc Dead End
Silver Grey
4ft / 1115mm
 T8-WH
  1-Circuit Track, 230V, inc Dead End
  White
  8ft / 2335mm
 T8-BL
1-Circuit Track, 230V, inc Dead End
Black
8ft / 2335mm
 T8-SG
 1-Circuit Track, 230V, inc Dead End
 Silver Grey
 8ft / 2335mm
 T12-WH
  1-Circuit Track, 230V, inc Dead End
  White
  12ft / 3555mm
 T12-BL
 1-Circuit Track, 230V, inc Dead End
 Black
 12ft / 3555mm
 T12-SG
 1-Circuit Track, 230V, inc Dead End
 Silver Grey
 12ft / 3555mm
       Live Ends, Dead Ends & Connectors
T4-WH T4-BL T4-SG
T38
T23
T24
T35
T29 Track Adaptors
T39
T20
T25
TDE1
T24
T26
90o
   Part No.
Description
Colour/ Finish
Length
 T38-WH
  Live End, Incoming Mains End Feed
  White
  82mm
 T38-BL
Live End, Incoming Mains End Feed
Black
82mm
 T38-SG
 Live End, Incoming Mains End Feed
 Silver Grey
 82mm
 T39-WH
  Centre Feed
  White
  118 x 118mm
 T39-BL
Centre Feed
Black
118 x 118mm
 TDE1-WH
  Dead End With Fixing Screw
  White
  3mm
 TDE1-BL
Dead End With Fixing Screw
Black
3mm
 TDE1-SG
 Dead End With Fixing Screw
 Silver Grey
 3mm
 T23-WH
  Straight Connector
  White
  8mm
 T23-BL
Straight Connector
Black
8mm
 T23-SG
  Straight Connector
  Silver Grey
  8mm
 T20-WH
Flexible Connector 00 to 1580
White
160mm
 T20-BL
  Flexible Connector 00 to 1580
  Black
  160mm
 T24-WH
 Adjustable Connector 900 or 1800
 White
 900 - 70 x 70mm 1800 - 105mm
 T24-BL
Adjustable Connector 900 or 1800
Black
900 - 70 x 70mm 1800 - 105mm
 T25-WH
  ‘T' Connector, Dual Polarity
  White
  70 x 105mm
 T25-BL
‘T' Connector, Dual Polarity
Black
70 x 105mm
 T26-WH
  ‘X' Connector, Requires Two Live Ends
  White
  105 x 105mm
 T26-BL
 ‘X' Connector, Requires Two Live Ends
 Black
 105 x 105mm
     180o
    T37F
T32
  Suspensions & T Bar Attachment
T33
 Part No.
Description
Colour/ Finish
Length
 T35(3000)
  Adjustable Suspension Wire
  -
  3000mm
 T35(6000)
Adjustable Suspension Wire
-
6000mm
 T37F
 T Bar Attachment Clip
 Silver
 -
 T33-WH(500)
  Suspension Rod, Max Loading 10kg Per Rod
  White
  500mm
 T33-BL(500)
Suspension Rod, Max Loading 10kg Per Rod
Black
500mm
 T33-SG(500)
  Suspension Rod, Max Loading 10kg Per Rod
  Silver Grey
  500mm
 T33-WH(1000)
Suspension Rod, Max Loading 10kg Per Rod
White
1000mm
 T33-BL(1000)
  Suspension Rod, Max Loading 10kg Per Rod
  Black
  1000mm
 T33-SG(1000)
 Suspension Rod, Max Loading 10kg Per Rod
 Silver Grey
 1000mm
   Part No.
 Description
 Colour/ Finish
 T29-WH/S
Switched Track Adapter -
Pre Wired with 1500mm Cable, 1kg Max Load
White
 T29-BL/S
  Switched Track Adapter -
Pre Wired with 1500mm Cable, 1kg Max Load
  Black
 T32-WH/S
 Switched Track Adapter With Ring-
Pre Wired with 1500mm Cable, 5kg Max Load
 White
 T32-BL/S
 Switched Track Adapter With Ring-
Pre Wired with 1500mm Cable, 5kg Max Load
 Black
