                    LIGHTING Fire-Rated Downlights
Evofire+ White 70mm Cut-Out
FR Downlight with Dimmable Lamp
Evofire+ Satin Nickel 70mm Cut-Out FR Downlight with Dimmable Lamp
          The latest innovation in Fire-rated Downlights.
• Low profile and easy to install and remove
• Attractive 1mm blend in bezel
• Insulation guard option
• Fire-resistant glass and steel body
• 30/60/90 min Fire-rated
compliance
• IP65 – Ideal for bathrooms • Easy wire - a loop-in/out
connector
• Evolight lamp included
      Part No. Description Watts Lumens CCT Beam Angle
 ILDLFR70D031
 White Round 70mm Cut-Out
 3.8
 390
2700
 36
 ILDLFR70D032
 White Round 70mm Cut-Out
 3.8
 400
4000
 36
 ILDLFR70D022
  White Round 70mm Cut-Out with Guard
  3.8
  390
 2700
 36
 ILDLFR70D023
 White Round 70mm Cut-Out with Guard
 3.8
 400
 4000
36
  Part No. Description Watts Lumens CCT Beam Angle
 ILDLFR70D035
 Satin Round 70mm Cut-Out
 3.8
 390
2700
 36
 ILDLFR70D036
 Satin Round 70mm Cut-Out
 3.8
 400
4000
 36
 ILDLFR70D026
  Satin Round 70mm Cut-Out with Guard
  3.8
  390
 2700
 36
 ILDLFR70D027
 Satin Round 70mm Cut-Out with Guard
 3.8
 400
 4000
36
    Evofire+ Polished Chrome 70mm Cut-Out FR Downlight with Dimmable Lamp
Evolight
Low Profile Lamp
Evolight Quick and Easy - alternative for MR16 installation
All in one solution – no need for a lamp holder or transformer. Perfect for Evofire products.
        eveovlioglhigtht
   • Low profile ( 29mm)
• Dimmable
• No need for a driver – direct
power connection
• Option with a loop in/out junction box
  Part No. Description Watts Lumens CCT Beam Angle
 ILDLFR70D033
 Chrome Round 70mm Cut-Out
 3.8
 390
2700
 36
 ILDLFR70D034
 Chrome Round 70mm Cut-Out
 3.8
 400
4000
 36
 ILDLFR70D024
  Chrome Round 70mm Cut-Out with Guard
  3.8
  390
 2700
 36
 ILDLFR70D025
 Chrome Round 70mm Cut-Out with Guard
 3.8
 400
 4000
36
  Part No. Description Watts Lumens CCT Beam Angle
 ILMDC001
 Evolight Dimmable without Junction Box
 3.8
 410
2700
 36
 ILMDE002
 Evolight Dimmable without Junction Box
 3.8
 420
4000
 36
 ILMDC003
  Evolight Dimmable with Junction Box
  3.8
  410
 2700
 36
 ILMDE004
 Evolight Dimmable with Junction Box
 3.8
 420
 4000
36
