Page 678 - Fegime - Electrical Product Guide Issue 1 V5
P. 678

                    LIGHTING
Downlights
 Eyebrook Downlights Eyebrook 3CCT Dome
Semi - Specular 80o
Eyebrook UGR Lens Semi - Specular UGR 60o
     IP54 3CCT
80o
5 YR Warranty
Specular Reflector
Anti Tamper Trim
IP54 <19
UGR 60o
Black Reflector
5 YR Warranty
Reflectors
       Eyebrook Dome
• 5 Year Warranty
• Interchangeable reflectors and trims. See accessories
• 3CCT - 3000K | 4000K | 6000K
Eyebrook Lens
• 5 Year Warranty
• 60o beam angle
• Interchangeable reflectors and trims. See accessories
Eyebrook Accessories
• Aluminium heatsink provides excellent thermals • 80o beam angle
• IP54
• High efficiency up to 130Lm/W
• UGR <19
• Aluminium heatsink provides excellent thermals
Silver Reflector
White Reflector
Trims
     Halo Trim Trim Extenders
Drop Glass Trim 6” to 8” Extender
  Part No. Description Wattage Kelvin Luminous flux (lm) +/-10% Luminaire Efficacy (lm/W)
  430203
  Eyebrook LED Dome Downlight 12W 3CCT Semi Specular 80D 4" White
  12W
  3CCT
  772 | 866 | 851
  83
 430204
 Eyebrook LED Dome Downlight 16W 3CCT Semi Specular 80D 6" White
 16W
 3CCT
 1761 | 1920 | 1916
 105
 430205
 Eyebrook LED Dome Downlight 22W 3CCT Semi Specular 80D 6" White
 22W
 3CCT
 2273 | 2514 | 2472
 100
    Part No. Description Wattage Kelvin Luminous flux (lm) +/-10% Luminaire Efficacy (lm/W)
  430206
 Eyebrook LED Lens Downlight 13W 4000K UGR Semi Specular 60D 4" White
 13W
 4000K
 1150
 89
 430207
 Eyebrook LED Lens Downlight 18W 4000K UGR Semi Specular 60D 6" White
 18W
 4000K
 1979
 126
 430208
  Eyebrook LED Lens Downlight 25W 4000K UGR Semi Specular 60D 6" White
  25W
  4000K
  2704
  117
 430209
 Eyebrook LED Lens Downlight 35W 4000K UGR Semi Specular 60D 6" White
 35W
 4000K
 3522
 97
   Part No. Description
  430217
 Eyebrook 4" Bezel Black
 430218
  Eyebrook 6" Bezel Black
 430219
Eyebrook 4" Trim Anti-Tamper
 430220
 Eyebrook 4" Trim Drop Glass
 430221
 Eyebrook 4" Trim Halo
 430222
  Eyebrook 6" Trim Anti-Tamper
 430223
 Eyebrook 6" Trim Drop Glass
 430224
 Eyebrook 6" Trim Halo
  Part No. Description
  430210
 Down Light 6" to 8" extender
 430211
  Eyebrook 4" Reflector Specular
 430212
Eyebrook 4" Reflector Black
 430213
 Eyebrook 4" Reflector White
 430258
 Eyebrook 4" Reflector Silver
 430214
  Eyebrook 6" Reflector Specular
 430215
Eyebrook 6" Reflector Black
 430216
  Eyebrook 6" Reflector White
 430259
 Eyebrook 6" Reflector Silver
     678
