                                    766LIGHTINGTogether we GENERATE VALUESTART Downlight 5in1• A range of 5in1 non dimmable downlights with 3 colour temperature choice (3000K, 4000K or 6500K selected via a 3-way switch located on the back of the fixture) and 2 mounting methods (recessed or surface mounted)• 3 round sizes in diameters of 165mm, 227mm and 290mm• Multiple cut-out dimensions thanks to flexible brackets installed at the back of the fixture (cut-out can be adjusted from 50mm to 260mm depending on product size)• A range of lumens from 1150lm to 2300lm to meet the requirements for many household applications• Efficacy of up to 100lm/W (23W 4000K model)• PIR version available with adjustable lumens and daylight level and lumen levels (900-1800lm)• High-quality construction - includes PC material with aluminium heat spreader, PC diffuser and white bezel (RAL 9003)• Black bezels are available as an accessory and can be attached to the product thanks to the twist and lock mechanism• Loop-in / Loop-out box included for ease of installationPart No. Description Total System Power Consumption (W)Lumen Output (lm)Efficacy (lm/W)Colour Temperature (K)0053148 START Downlight 5in1 50-125 1150lm 12 1150 96 3000-4000-65000053149 START Downlight 5in1 65-185 1750lm 18 1750 97 3000-4000-65000053150 START Downlight 5in1 65-260 1800lm 18 1800 100 3000-4000-65000053151 START Downlight 5in1 65-260 2300lm 23 2300 100 3000-4000-65000053152 START Downlight 5in1 65-185 1800lm PIR 18 1800 100 3000-4000-6500Downlights AccessoriesPart No. Description0053156 Black Bezel 1760053157 Black Bezel 2280053158 Black Bezel 301BlackDownlightsSTART Downlight 5in1 125 START Downlight 5in1 185 START Downlight 5in1 185 PIR START Downlight 5in1 260
