P. 13

                    CABLE & ACCESSORIES
Accessories
Crimping Tool Kit/Terminal Installation Kit Interchangeable
• Full Cycle Ratchet crimper with 5 interchangeable die sets for insulated, non-insulated ferrule, cord-end, copper lugs and butt splice terminals
• Removable thumb screws for quick change of dies
• Built in safety ratchet mechanism provides precise crimping
• Angled head with streamlined ergonomic grips enhances operation
effectively & comfortably
• High leverage design structure of frame provides easy crimp action
• 5 Tools in one!
Assorted Cord Ends/Bootlace Ferrules (French & German)
• Contains: 8 Popular Sizes 0.52mm x 10.02mm
Jelly Crimps 8A 2 & 3 Way
• Contains: 8 Popular Sizes 0.52mm x 10.02mm
Brass Nickel Plated 32mm
• Lock Nuts Included
• Multiple inserts 16mm2 & 10mm2
• Single point entry for incoming tails preventing eddy currents • Blanking plug included if earth cable not required
• Provides an insulating barrier in TT installations
• IP68 ingress protection
• Lock Nuts Included
• Multiple inserts 16mm2 & 10mm2 & 25mm2 & 16mm2
• Single point entry for incoming tails preventing eddy currents • Blanking plug included if earth cable not required
• Provides an insulating barrier in TT installations
       Part No. Type
Crimp Tool
Part No. Type
  CEK2
  Cord Ends (French)
 CEK1
 Cord Ends (German)
          CTK Ratchet Crimping Tool Set (Comes with 5 dies)
  Dies
Part No. Type
     Die Set for Pin Terminal/Insulated or Non/Insulated Ferrules (Cord Ends)
  DL-5D2
Crimp dimension AWG 6 / 4 / 2 & DIN 16 / 25 / 35mm2
   DL-2E2
Crimp dimension AWG 22/ 20 / 18 / 16 / 14 / 12 / 10 / 8 / 6 & DIN 0.5 / 0.75 / 1.0 / 1.5 / 2.5 / 4 / 6 / 10 / 16mm2
  Die Set for Non Insulated Terminals and Copper Lugs/Butt Splices
  DL-2N
Crimp dimension AWG 20- 18 / 16- 14 / 12- 10 / 8 & DIN 1.5/ 2.5 / 6 / 10mm2
  DL-5N1
Crimp dimension AWG 8 / 6 / 4 & DIN 10 / 16 / 25mm2
Part No. Type Pack Qty
  JC2
  8A 2 Way
  100
 JC3
 8A 3 Way
 100
    Die Set for Insulated Terminals
    DL-2H
Brass & Nylon Tail Kits
Crimp dimension AWG 22-18 / 16- 14 / 12-10 & DIN 0.5-1 / 1.5-2.5/ 4.6mm2
       Part No. Size
  TKGB32     2 x 16mm2 + 1 x 10mm2 Nylon Tail Kits 32mm
    Part No. Size
  TKGN32
  2 x 16mm2 + 1 x 10mm2
 TKGN32L
2 x 25mm2 + 1 x 16mm2
    Together we
13
GENERATE VALUE
