Page 9 - Fegime - Electrical Product Guide Issue 1 V5
P. 9

                    CABLE & ACCESSORIES Pre-Insulated Crimp Terminals
Ring Terminal Copper
Fully Insulated Female
Blade Terminal Copper
• Finish: Tin Plated
• Voltage: 600V @ 75°C
• Insulated: Polyvinyl Chloride
     • Finish: Tin Plated
• Voltage: 600V @ 75°C
• Insulated: Polyvinyl Chloride
Electric Rating:
Blue - 27A Red - 19A Yellow - 24A
deligo
Push-On Terminal Brass
      TFR32
Terminals
• Finish: Tin Plated
• Voltage: 300V @ 75°C
• Insulated: Polyvinyl Chloride
Electric Rating:
Blue - 15A Red - 10A Yellow - 24A
    Part No. Type
  TRB32
 Blue 3.2
 TRB37
 Blue 3.7
 TRB43
 Blue 4.3
 TRB53
 Blue 5.3
 TRB64
 Blue 6.4
 TRB8
 Blue 8.4
 TRB10
 Blue 10.5
 TRR32
 Red 3.2
 TRR37
 Red 3.7
 TRR43
 Red 4.3
 TRR53
 Red 5.3
 TRR64
 Red 6.4
 TRR85
 Red 8.4
 TRR10
 Red 10.5
 TRY43
 Yellow 4.3
 TRY53
 Yellow 5.3
 TRY64
 Yellow 6.4
 TRY8
 Yellow 8.4
 TRY10
  Yellow 10.5
 TRY12
 Yellow 13.0
    Part No. Type
  TPFB48FI
 Blue 4.8
 TPFB63FI
 Blue 6.3
 TPFR28FI
 Red 2.8
 TPFR48FI
 Red 4.8
 TPFR63FI
 Red 6.3
 TPFY63FI
  Yellow 6.3
 TPFY95FI
 Yellow 9.5
   Part No. Type
  TBB18
 Blue 18.4mm
 TBR18
  Red 18.4mm
 TBY10
 Yellow 10.0mm
   Fork Terminal Copper
• Finish: Tin Plated
• Voltage: 600V @ 75°C
• Insulated: Polyvinyl Chloride
Electric Rating:
Blue - 27A Red - 19A Yellow - 24A
Piggy-Back Push-On
Electric Rating:
Blue - 27A Red - 19A Yellow - 24A
Male Push-On Terminal Brass
• Finish: Tin Plated
• Voltage: 300V @ 75°C
• Insulated: Polyvinyl Chloride
   Terminal Copper
  • Finish: Copper, Tin Plated
• Voltage: 300V @ 75°C
• Insulated: Polyvinyl Chloride
Electric Rating:
Blue - 15A Red - 10A Yellow - 24A
Electric Rating:
Blue - 15A Red - 10A Yellow - 24A
         Part No. Type
    TFB32
Blue 3.2
   TFB37
Blue 3.7
  TFB43
Blue 4.3
  TFB53
Blue 5.3
  TFB64
Blue 6.4
  Red 3.2
  TFR37
Red 3.7
Part No. Type
    TFR43
Red 4.3
     TFR53
Red 5.3
  TFR64
Red 6.4
Part No. Type
TPMB48
Blue 4.8
  TPMB
Blue 6.3
      TFY37
Yellow 3.7
TMPR28
Red 2.8
       TFY43
Yellow 4.3
TPPB
Red 6.3
TPMR48
Red 4.8
      TFY53
Yellow 5.3
TPPR
TPMR
Red 6.3
     TFY64
Yellow 6.4
TPPY
Blue 6.3
 Yellow 6.3
TPMY
Yellow 6.3
       Together we
9
GENERATE VALUE

   7   8   9   10   11
