143CABLE MANAGEMENTTogether we GENERATE VALUEMP1/6 MP1/8MP1/10 MP1/12demon catSquare Plate Washers• All HDG finish and manufactured in accordance with BS6946Easyfit Channel NutPart No. DescriptionMP1/6 6mm Square WasherMP1/8 8mm Square WasherMP1/10 10mm Square WasherMP1/12 12mm Square WasherPart No. DescriptionEF6 M6 Easyfit Channel Nut - GreyEF8 M8 Easyfit Channel Nut - YellowEF10 M10 Easyfit Channel Nut - BlueEF12 M12 Easyfit Channel Nut - Blue/RedChannel AccessoriesSteel ChannelPart No. DescriptionMPC1/3 41 x 41mm / 3mtr Plain Steel ChannelMPC2/3 41 x 41mm / 3mtr Slotted Steel ChannelMPC6/3 41 x 21mm / 3mtr Plain Steel ChannelMPC7/3 41 x 21mm / 3mtr Slotted Steel ChannelMPC1/6 41 x 41 x 2.5mm Channel Plain 6mtrMPC2/6 41 x 41 x 2.5mm Channel Slotted 6mtrMPC6/6 41 x 21 x 2.5mm Channel Plain 6mtrMPC7/6 41 x 21 x 2.5mm Channel Slotted 6mtrPart No. DescriptionTR6 M6 x 3mtr Threaded Rod - BZPTR8 M8 x 3mtr Threaded Rod - BZPTR10 M10 x 3mtr Threaded Rod - BZPTR12 M12 x 3mtr Threaded Rod - BZPTRC6 M6 x 18mm Threaded Rod Connector - BZPTRC8 M8 x 24mm Threaded Rod Connector - BZPTRC10 M10 x 30mm Threaded Rod Connector - BZPTRC12 M12 x 36mm Threaded Rod Connector - BZPThreaded Rod & Connectors• Offering over 30% labour savings and designed for the installer, the Easyfit Channel Nut is exclusive to Demon Cato as part of our Innovations range, and also ensures a safer working environment for the end-user• Produced to comply with the requirements of BS6946: Metal Channel Support Systems and fully RoHS 2 compliant • Part of the Demon Cato Innovations range• Extended 5 Year Warranty when installed as a system• Compliant to BSEN10346• Meets the mechanical strength of BS6946:1998• Fully compliant to DIN975 with a 60° angle thread on each length & connector• Manufactured from 4.8 grade steel• Compliant to RoHS2Spring Nuts• All Metpro channel nuts are compliant to BS6946 with M6, M8, M10 & M12 sizes available in BZP, HDG & 316 stainless steel finishes• For use with 21mm and 41mm Depth Channel• Authorised for use on London Underground to LU Standard 1-085 (for use on surface & sub-surface locations)• Fully RoHS 2 compliant Part No. DescriptionCS20 M6 Plain Spring NutCS21 M8 Plain Spring NutCS22 M10 Plain Spring NutCS23 M12 Plain Spring NutCS24 M6 Short Spring NutCS25 M8 Short Spring NutCS26 M10 Short Spring NutCS27 M12 Short Spring NutCS28 M6 Long Spring NutCS29 M8 Long Spring NutCS30 M10 Long Spring NutCS31 M12 Long Spring NutCS24 CS28Please use suffix /GA for HDG or /SS for Stainless Steel optionsCS20MPC7/3TR6 TRC6MPC1/3
