                    CABLE MANAGEMENT Steel Trunking
Steel Trunking
A whole range of cable trunking and accessories that generally complies with BS EN 50085-1:2005 & BS EN 50085-2-1:2006.
Manufactured from hot dipped galvanised sheet steel/coil to BS EN 10346:2015 (i.e. pre-galvanised).
Trunking is supplied in 3mtr lengths as standard. Alternative sizes, multi compartment and Powder Coated Finishes are also available upon request.
Trench Cable Trunking range can easily be made compliant to IP4X by using our standard “off the shelf” IP4X Lid Fix Bar & IP4X Outer “U” Piece - simply add one per joint to ensure the installation is compliant.
trench obo bettermann
   Part No. Description
    90o Top Cover Bend
90o Internal Cover Bend
90o External Cover Bend
ST22
50x50mm Pre Galv Cable Trunking 3m
  ST33
75x75mm Pre Galv Cable Trunking 3m
  ST42
100x50mm Pre Galv Cable Trunking 3m
  ST44
100x100mm Pre Galv Cable Trunking 3m
  ST66
150x150mm Pre Galv Cable Trunking 3m
        Part No. Description
Part No. Description
            SA2290T
45o Top Cover Bend
45o Internal Cover Bend
45o External Cover Bend
50x50mm Trunking Top Cover 90o Bend
SA2290I
50x50mm Trunking Internal Cover 90o Bend
     SA3390T
75x75mm Trunking Top Cover 90o Bend
SA3390I
75x75mm Trunking Internal Cover 90o Bend
    SA4290T
100x50mm Trunking Top Cover 90o Bend
SA4290I
  SA4490T
100x100mm Trunking Top Cover 90o Bend
  SA6690T
150x150mm Trunking Top Cover 90o Bend
SA6690I
100x50mm Trunking Internal Cover 90o Bend
Part No. Description
   SA2290E
SA6690E
50x50mm Trunking External Cover 90o Bend
 SA3390E
75x75mm Trunking External Cover 90o Bend
  SA4290E
100x50mm Trunking External Cover 90o Bend
    SA4490I
100x100mm Trunking Internal Cvr 90o Bend
SA4490E
100x100mm Trunking External Cvr 90o Bend
    150x150mm Trunking Internal Cvr 90o Bend
150x150mm Trunking External Cvr 90o Bend
            Part No. Description
  SA2245T
 50x50mm Trunking Top Cover 45o Bend
 SA3345T
 75x75mm Trunking Top Cover 45o Bend
 SA4245T
 100x50mm Trunking Top Cover 45o Bend
 SA4445T
  100x100mm Trunking Top Cover 45o Bend
 SA6645T
 150x150mm Trunking Top Cover 45o Bend
  Part No. Description
  SA2245I
 50x50mm Trunking Internal Cover 45o Bend
 SA3345I
 75x75mm Trunking Internal Cover 45o Bend
 SA4245I
 100x50mm Trunking Internal Cover 45o Bend
 SA4445I
  100x100mm Trunking Internal Cvr 45o Bend
 SA6645I
 150x150mm Trunking Internal Cvr 45o Bend
  Part No. Description
  SA2245E
 50x50mm Trunking External Cover 45o Bend
 SA3345E
 75x75mm Trunking External Cover 45o Bend
 SA4245E
 100x50mm Trunking External Cover 45o Bend
 SA4445E
  100x100mm Trunking External Cvr 45o Bend
 SA6645E
 150x150mm Trunking External Cvr 45o Bend
     Top Cover Tee
Internal Cover Tee
External Cover Tee
      Part No. Description
 Part No. Description
  SA22TIN
 50x50mm Trunking Internal Cover Tee
 SA33TIN
 75x75mm Trunking Internal Cover Tee
 SA42TIN
 100x50mm Trunking Internal Cover Tee
 SA44TIN
  100x100mm Trunking Internal Cover Tee
 SA66TIN
 150x150mm Trunking Internal Cover Tee
  Part No. Description
  SA22TEX
 50x50mm Trunking External Cover Tee
 SA33TEX
 75x75mm Trunking External Cover Tee
 SA42TEX
 100x50mm Trunking External Cover Tee
 SA44TEX
  100x100mm Trunking External Cover Tee
 SA66TEX
 150X150mm Trunking External Cover Tee
       SA22TTC
50x50mm Trunking Top Cover Tee
  SA33TTC
75x75mm Trunking Top Cover Tee
  SA42TTC
100x50mm Trunking Top Cover Tee
  SA44TTC
100x100mm Trunking Top Cover Tee
  SA66TTC
150x150mm Trunking Top Cover Tee
