P. 148

                    CABLE MANAGEMENT Cable Tray & Accessories
Light Duty Cable Tray Lengths
Manufactured from hot dipped galvanised steel sheet/coil to BS EN 10346:2015
(i.e. pre-galvanised) and generally conforms to BS EN 61537-2007. Also available in Hot Dipped Galvanised and Powder Coated Finish.
All lengths supplied in 3 Metres.
Wider Sizes and a wider range of accessories are also available.
Steel Pre Galv Cable T
Light Duty Cable Tray Flat 90o Bend
s
Light Duty Cable Tray Flat 45o Bend
 Part No. Description
  LDT050TR
  50mm Light Duty Pre Galv Cable Tray-3m
 LDT075TR
75mm Light Duty Pre Galv Cable Tray-3m
 LDT100TR
 100mm Light Duty Pre Galv Cable Tray-3m
 LDT150TR
  150mm Light Duty Pre Galv Cable Tray-3m
 LDT225TR
225mm Light Duty Pre Galv Cable Tray-3m
 LDT300TR
 300mm Light Duty Pre Galv Cable Tray-3m
 LDT450TR
  450mm Light Duty Pre Galv Cable Tray-3m
 LDT600TR
 600mm Light Duty Pre Galv Cable Tray-3m
     ray - Light Duty Accessorie
     Part No. Description
  LDT050FB
 50mm Light Duty Cable Tray Flat 90o Bend
 LDT075FB
  75mm Light Duty Cable Tray Flat 90o Bend
 LDT100FB
100mm Light Duty Cable Tray Flat 90o Bend
 LDT150FB
 150mm Light Duty Cable Tray Flat 90o Bend
 LDT225FB
 225mm Light Duty Cable Tray Flat 90o Bend
 LDT300FB
  300mm Light Duty Cable Tray Flat 90o Bend
 LDT450FB
 450mm Light Duty Cable Tray Flat 90o Bend
 LDT600FB
 600mm Light Duty Cable Tray Flat 90o Bend
  Part No. Description
  LDT050HB
 50mm Light Duty Cable Tray Flat 45o Bend
 LDT075HB
  75mm Light Duty Cable Tray Flat 45o Bend
 LDT100HB
100mm Light Duty Cable Tray Flat 45o Bend
 LDT150HB
 150mm Light Duty Cable Tray Flat 45o Bend
 LDT225HB
 225mm Light Duty Cable Tray Flat 45o Bend
 LDT300HB
  300mm Light Duty Cable Tray Flat 45o Bend
 LDT450HB
 450mm Light Duty Cable Tray Flat 45o Bend
 LDT600HB
 600mm Light Duty Cable Tray Flat 45o Bend
     Light Duty Cable Tray Flat Tee
Light Duty Cable Tray Ext 90o Bend
   Part No. Description
  LDT050FT
 50mm Light Duty Cable Tray Flat Tee
 LDT075FT
 75mm Light Duty Cable Tray Flat Tee
 LDT100FT
 100mm Light Duty Cable Tray Flat Tee
 LDT150FT
 150mm Light Duty Cable Tray Flat Tee
 LDT225FT
  225mm Light Duty Cable Tray Flat Tee
 LDT300FT
300mm Light Duty Cable Tray Flat Tee
 LDT450FT
  450mm Light Duty Cable Tray Flat Tee
 LDT600FT
 600mm Light Duty Cable Tray Flat Tee
  Part No. Description
  LDT050EX
 50mm Light Duty Cable Tray Ext 90o Bend
 LDT075EX
 75mm Light Duty Cable Tray Ext 90o Bend
 LDT100EX
 100mm Light Duty Cable Tray Ext 90o Bend
 LDT150EX
 150mm Light Duty Cable Tray Ext 90o Bend
 LDT225EX
  225mm Light Duty Cable Tray Ext 90o Bend
 LDT300EX
300mm Light Duty Cable Tray Ext 90o Bend
 LDT450EX
  450mm Light Duty Cable Tray Ext 90o Bend
 LDT600EX
 600mm Light Duty Cable Tray Ext 90o Bend
      Light Duty Cable Tray Int 90o Bend
Light Duty Cable Tray 4Way
  Part No. Description
  LDT050IN
 50mm Light Duty Cable Tray Int 90o Bend
 LDT075IN
 75mm Light Duty Cable Tray Int 90o Bend
 LDT100IN
  100mm Light Duty Cable Tray Int 90o Bend
 LDT150IN
150mm Light Duty Cable Tray Int 90o Bend
 LDT225IN
 225mm Light Duty Cable Tray Int 90o Bend
 LDT300IN
 300mm Light Duty Cable Tray Int 90o Bend
 LDT450IN
  450mm Light Duty Cable Tray Int 90o Bend
 LDT600IN
 600mm Light Duty Cable Tray Int 90o Bend
  Part No. Description
  LDT050FW
 50mm Light Duty Cable Tray 4Way
 LDT075FW
 75mm Light Duty Cable Tray 4Way
 LDT100FW
  100mm Light Duty Cable Tray 4Way
 LDT150FW
150mm Light Duty Cable Tray 4Way
 LDT225FW
 225mm Light Duty Cable Tray 4Way
 LDT300FW
 300mm Light Duty Cable Tray 4Way
 LDT450FW
  450mm Light Duty Cable Tray 4Way
 LDT600FW
 600mm Light Duty Cable Tray 4Way
     148
