P. 150

                    CABLE MANAGEMENT
Cable Tray & Accessories
Heavy Duty Cable Tray Lengths
  Part No. Description
  HDT050TR
 50mm Heavy Duty Pre Galv Cable Tray-3m
 HDT075TR
 75mm Heavy Duty Pre Galv Cable Tray-3m
 HDT100TR
 100mm Heavy Duty Pre Galv Cable Tray-3m
 HDT150TR
  150mm Heavy Duty Pre Galv Cable Tray-3m
 HDT225TR
225mm Heavy Duty Pre Galv Cable Tray-3m
 HDT300TR
 300mm Heavy Duty Pre Galv Cable Tray-3m
 HDT450TR
  450mm Heavy Duty Pre Galv Cable Tray-3m
 HDT600TR
 600mm Heavy Duty Pre Galv Cable Tray-3m
    Manufactured from hot dipped galvanised steel sheet/coil to BS EN 10346:2015
(i.e. pre-galvanised) and generally conforms to BS EN 61537-2007. Also available in Hot Dipped Galvanised and Powder Coated Finish.
All lengths supplied in 3 Metres. Wider Sizes and a wider range of accessories are also available.
Steel Pre Galv Ca
Heavy Duty Cable Tray Flat 90o Bend
ries
Heavy Duty Cable Tray Internal 90o Bend
    Part No. Description
 Part No. Description
  HDT050IN
 50mm Heavy Duty Cable Tray Int 90o Bend
 HDT075IN
  75mm Heavy Duty Cable Tray Int 90o Bend
 HDT100IN
100mm Heavy Duty Cable Tray Int 90o Bend
 HDT150IN
 150mm Heavy Duty Cable Tray Int 90o Bend
 HDT225IN
 225mm Heavy Duty Cable Tray Int 90o Bend
 HDT300IN
  300mm Heavy Duty Cable Tray Int 90o Bend
 HDT450IN
 450mm Heavy Duty Cable Tray Int 90o Bend
 HDT600IN
 600mm Heavy Duty Cable Tray Int 90o Bend
    HDT100FB
ble Tray - Heavy D
50mm Heavy Duty Cable Tray Flat 90o Bend
uty Accesso
    HDT050FB
  HDT075FB
75mm Heavy Duty Cable Tray Flat 90o Bend
  100mm Heavy Duty Cable Tray Flat 90o Bend
  HDT150FB
150mm Heavy Duty Cable Tray Flat 90o Bend
  HDT225FB
225mm Heavy Duty Cable Tray Flat 90o Bend
  HDT300FB
300mm Heavy Duty Cable Tray Flat 90o Bend
  HDT450FB
450mm Heavy Duty Cable Tray Flat 90o Bend
  HDT600FB
600mm Heavy Duty Cable Tray Flat 90o Bend
    Heavy Duty Cable Tray Flat Tee
Heavy Duty Cable Tray External 90o Bend
  Part No. Description
 Part No. Description
  HDT050EX
  50mm Heavy Duty Cable Tray Ext 90o Bend
 HDT075EX
75mm Heavy Duty Cable Tray Ext 90o Bend
 HDT100EX
 100mm Heavy Duty Cable Tray Ext 90o Bend
 HDT150EX
 150mm Heavy Duty Cable Tray Ext 90o Bend
 HDT225EX
  225mm Heavy Duty Cable Tray Ext 90o Bend
 HDT300EX
300mm Heavy Duty Cable Tray Ext 90o Bend
 HDT450EX
  450mm Heavy Duty Cable Tray Ext 90o Bend
 HDT600EX
 600mm Heavy Duty Cable Tray Ext 90o Bend
       HDT050FT
50mm Heavy Duty Cable Tray Flat Tee
  HDT075FT
75mm Heavy Duty Cable Tray Flat Tee
  HDT100FT
100mm Heavy Duty Cable Tray Flat Tee
  HDT150FT
150mm Heavy Duty Cable Tray Flat Tee
  HDT225FT
HDT300FT
225mm Heavy Duty Cable Tray Flat Tee
  300mm Heavy Duty Cable Tray Flat Tee
  HDT450FT
450mm Heavy Duty Cable Tray Flat Tee
  HDT600FT
600mm Heavy Duty Cable Tray Flat Tee
    Heavy Duty Cable Tray Flat 45o Bend
Heavy Duty Cable Tray 4Way
  Part No. Description
Part No. Description
  HDT050HB
 50mm Heavy Duty Cable Tray Flat 45o Bend
 HDT075HB
 75mm Heavy Duty Cable Tray Flat 45o Bend
 HDT100HB
 100mm Heavy Duty Cable Tray Flat 45o Bend
 HDT150HB
  150mm Heavy Duty Cable Tray Flat 45o Bend
 HDT225HB
225mm Heavy Duty Cable Tray Flat 45o Bend
 HDT300HB
 300mm Heavy Duty Cable Tray Flat 45o Bend
 HDT450HB
  450mm Heavy Duty Cable Tray Flat 45o Bend
 HDT600HB
 600mm Heavy Duty Cable Tray Flat 45o Bend
        Heavy Duty Cable Tray couplers
HDT050FW
50mm Heavy Duty Cable Tray 4Way
  HDT075FW
75mm Heavy Duty Cable Tray 4Way
  HDT100FW
HDT225FW
100mm Heavy Duty Cable Tray 4Way
  HDT150FW
150mm Heavy Duty Cable Tray 4Way
  225mm Heavy Duty Cable Tray 4Way
  HDT300FW
300mm Heavy Duty Cable Tray 4Way
  HDT450FW
450mm Heavy Duty Cable Tray 4Way
  HDT600FW
600mm Heavy Duty Cable Tray 4Way
    Part No. Description
   HDTSC     Heavy Duty Cable Tray couplers (pair)
