P. 198

                    WIRING ACCESSORIES Vimark Metalclad
Socket Outlets
Plate Switches
Connection Units
           • Durable and tough finish with protective coating with front plates that fit flush to the back box
• Terminals have clear embossed and white printed markings
• Recessed earth bar
• Captive and backed out, top facing terminals
with large cable lead-ins
• Only one size 4mm screwdriver needed
• Supplied complete with surface mounting box
with knockouts
• 25-year guarantee
• BS EN 1363: Part 2
Unswitched
Switched
USB Charging Socket Outlets
• Durable and tough finish with protective coating with front plates that fit flush to the back box
• USB ports deliver up to 4.0A (3.0A + 1.0A) simultaneous charging current across 3 ports
• Uses auto IC technology to detect connected devices and provide optimised high-speed charging
• Single pole switch with concave rockers
• Captive and backed out, top facing terminals with large cable lead-ins and clear embossed markings
• Supplied complete with surface mounting box with knockouts
• Only one size 4mm screwdriver needed
• 2-year guarantee
• BS EN 1363: Part 2
• Durable and tough finish with protective coating with front plates that fit flush to the back box
• Concave rocker
• Terminals have clear embossed and white
printed terminals
• Complete with surface mounting box with
knockouts
• All plate switches are X-rated and can be used
for switching inductive or fluorescent loads
without de-rating
• Captive and backed out terminals with large
cable lead-ins
• Only one size 4mm screwdriver needed • 25-year guarantee
• BS EN 60669-1
Double Pole Switches
• Durable and tough finish with protective coating with front plates that fit flush to the back box
• Complete with surface mounting box with knockouts
• Terminals have clearly embossed and white printed markings
• Captive and backed out colour coded terminals with large cable lead-ins
• 2 earth terminals • 25-year guarantee • BS EN 60669-1
• Durable and tough finish with protective coating with front plates that fit flush to the back box
• Terminals have clear embossed and white printed markings
• Lockable, captive fuse carrier for safety isolation • Captive and backed out, top facing terminals
with large cable lead-ins
• Only one size 4mm screwdriver needed
• Supplied complete with surface mounting box
with knockouts
• 25-year guarantee • BS 1363: Part 4
 Part No. Description
  M1206
  1g 13A Unswitched Socket
 M1208
 2g 13A Unswitched Socket
     Part No. Description
       M1203
1g 2w 10AX Plate Switch
M1212
13A Switch Spur Neon
       M1207DP
1g 13A Switched Socket DP
M1204
2g 2w 10AX Plate Switch
   M1209DP
2g 13A Switched Socket DP
M1205
        Part No. Description
  M1200
 1g Blank Plate
 M1201
 2g Blank Plate
 M1228N
  1g Back Box with No Knockouts
 M1229N
 2g Back Box with No Knockouts
 198
Metalclad Blank Plates and Boxes
• Durable and tough finish with protective coating with front plates that fit flush to the back box
• 25-year guarantee • BS 5733
Metalclad Data Plates
• Durable and tough finish with protective coating with front plates that fit flush to the back box
• Accepts 50x25mm euro modules
• Full range of power, TV & data modules available
• 25-year guarantee • BS 5733
GENERATE VALUE
Part No. Description
3g 2w 10AX Plate Switch
Part No. Description
   M1210
M1210FL
M1212FL
13A Unswitch Spur
  13A Unswitch Spur & F/O
  Part No. Description
M1211
13A Switch Spur
   M1211FL
13A Switch Spur & F/O
  M1217
13A Switch Spur Neon & F/O
 13A Unswitch Spur Neon
             Part No. Description
M1213
 Part No. Description
   M1222 Two Module Data Plate
   M1214
20A DP Switch
 20A DP Switch Neon
    M1299 2g 13A SP Switched Socket + 3 USB Ports (4A)
M1300P
50A DP Switch Neon
