P. 199

                    WIRING ACCESSORIES Ultra Flatplate
Socket Outlets - Switched
Plate Switches
Ultra Flatplate Ordering Guide
Chrome or Stainless Steel Finish available with either Black or White Inserts
FINISH INSERTS
CHor SSwith B or W
When ordering products please indicate finish and insert preference by adding the suffixes shown above to the Part No.
         • Ultra slim metal profile
• Double pole switch with concave colour matched
metal rocker
• Terminals have clear embossed and white
printed markings
• Protective film on frontplate prevents damage
during installation
• Foam gasket pre-fitted to the accessory to
prevent tarnishing
• Captive and backed out, top facing, colour coded
terminals with large cable lead-ins
• Only one size 4mm screwdriver needed
• Recessed earth bar
• 25-year guarantee
• BS EN 1363: Part 2
USB Charging Socket Outlets
• Ultra slim metal profile
• USB ports deliver up to 4.0A (3.0A + 1.0A)
simultaneous charging current across 3 ports
• Uses auto IC technology to detect connected
devices and provide optimised high-speed
charging
• Single pole switch with concave colour matched
metal rockers
• Foam gasket pre-fitted to the accessory to
prevent tarnishing
• Captive and backed out, top facing, colour coded
terminals with large cable lead-ins and clear
embossed and white printed markings
• Fits Deta 25mm flush metal and 35mm dry
lining boxes
• Protective film on frontplate prevents damage
during installation
• 2-year guarantee
• BS EN 1363: Part 2
GENERATE VALUE
• Ultra slim metal profile
• Concave colour matched metal rocker
• Terminals have clear embossed and white
printed markings
• Protective film on frontplate prevents damage
during installation
• Foam gasket pre-fitted to the accessory to
prevent tarnishing
• X-rated, can be used for switching inductive or
fluorescent loads without de-rating
• Captive and backed out terminals with large
cable lead-ins
• 25-year guarantee • BS EN 60669-1
Connection Units
• Ultra slim metal profile
• Terminals have clear embossed and white
printed markings
• Lockable, captive fuse carrier for safety isolation • Foam gasket pre-fitted to the accessory to
prevent tarnishing
• Captive and backed out, top facing, colour coded
terminals with large cable lead-ins
• Only one size 4mm screwdriver needed
• Protective film on frontplate prevents damage
during installation • 25-year guarantee • BS 1363: Part 4
Dimmer Switches
• Ultra slim metal profile
• Universal dimmers suitable for use with
dimmable LED lamps (requiring leading or trailing edge control), incandescent and halogen lamps or low voltage lighting
• Suitable for loads up to 250W LED, 350W incandescent / halogen
Push on / push off dimmers are suitable for multiway dimming
• Colour matched dimmer knob
Protective film on frontplate prevents damage during installation
Foam gasket pre-fitted to the accessory to prevent tarnishing
• Spare dimmer knobs available • 2-year guarantee
• BS EN 60669-2-1
Cooker Control Units
• Ultra slim metal profile
• Concave colour matched metal rockers with grey
font switch markings
• 45A rated switch
• Captive and backed out, top facing, colour coded
terminals with large cable lead-ins and clear
embossed and white printed markings
• Foam gasket pre-fitted to the accessory to
prevent tarnishing
• Two earth terminals
• Protective film on frontplate prevents damage
during installation
25-year guarantee • BS 4177
  Part No. Description
  8131
  1g 13A Switched Socket DP
 8132
 2g 13A Switched Socket DP
                  Together we
199
Part No. Description
   8101
1g 2w 10AX Plate Switch
•
  8102
2g 2w 10AX Plate Switch
  Part No. Description
8103
3g 2w 10AX Plate Switch
• 1g Intermediate 10AX Plate Switch •
  8104 8106
4g 2w 10AX Plate Switch
    8107
3 Pole Fan Isolator 10A
  Part No. Description
   Part No. Description
8130 2g 250W Universal Dimmer Multiway
      8174 2g 13A SP Sw Skt + 3 USB Ports (4A)
8142
13A Switch Spur
•
Part No. Description
   8143
13A Switch Spur Neon
    8144
13A Switch Spur Neon & F/O
8154 Cooker Control Unit Neon
