P. 255

                    WIRING ACCESSORIES
Din Rail Terminals & End Plates
Din Rail Terminals     Push Button Din Rail Terminals
   • • •
•
60% faster than screws Accepts all conductor types Solid & ferruled conductors push straight in
Suitable for 35mm DIN rail.
• 60% faster than screws
• Accepts all conductor types • Solid conductors push
straight in
• Suitable for 35mm DIN rail • Push Buttons for easy
operation
Part No. Description
 Part No. Description
  2202-1201
  Through terminal 2.5mm2 Grey
 2202-1204
Through terminal 2.5mm2 Blue
 2202-1207
 Through terminal 2.5mm2 Green/Yellow
 2204-1201
 Through terminal 4mm2 Grey
 2204-1204
  Through terminal 4mm2 Blue
 2204-1207
Through terminal 4mm2 Green/Yellow
 2206-1201
 Through terminal 6mm2 Grey
 2206-1204
  Through terminal 6mm2 Blue
 2206-1207
 Through terminal 6mm2 Green/Yellow
       2002-1201
 2002-1204
2010-1201
Through terminal 2.5mm2 Grey
 Through terminal 2.5mm2 Blue
  2002-1207
Through terminal 2.5mm2 Green/Yellow
  2004-1201
Through terminal 4mm2 Grey
  2004-1204
2004-1207
2006-1201
Through terminal 4mm2 Blue
  Through terminal 4mm2 Green/Yellow
  Through terminal 6mm2 Grey
  2006-1204
Through terminal 6mm2 Blue
  2006-1207
Through terminal 6mm2 Green/Yellow
  Through terminal 10mm2 Grey
   2010-1204 2010-1207
Through terminal 10mm2 Blue Through terminal 10mm2 Green/Yellow
    2016-1201
Through terminal 16mm2 Grey
  2016-1204
  2016-1207
 •
2 Way Jumpers
2 way Jumper for 2.5mm2, 4mm2, 6mm2, 10mm2 & 16mm2 terminals
Lever Din Rail Terminals
• 60% faster than screws
• Accepts all conductor types • Solid conductors push
straight in
• Suitable for 35mm DIN rail • Lever & Push Buttons for
easy operation
 Part No. Description
  2104-5201
 Through terminal 4mm2 Grey
 2104-5204
  Through terminal 4mm2 Blue
 2104-5207
Through terminal 4mm2 Green/Yellow
 2106-5201
 Through terminal 6mm2 Grey
 2106-5204
  Through terminal 6mm2 Blue
 2106-5207
 Through terminal 6mm2 Green/Yellow
  Part No. Description
Through terminal 16mm2 Blue
 Through terminal 16mm2 Green/Yellow
       2002-402
2 way Jumper 2.5mm2
  2004-402
2 Way Jumper 4mm2 Grey
  2006-402
2 Way Jumper 6mm2 Grey
  2010-402
2 Way Jumper 10mm2 Grey
  2016-402
2 Way Jumper 16mm2 Grey
  End Plates     End Plates
•
End Plates for 2.5mm2, 4mm2, 6mm2, 10mm2 & 16mm2 terminals
• End Plates for 2104 & 2106 series
  Part No. Description
 Part No. Description
  2104-1291
  End Plates 4mm2 Grey
 2106-1291
 End Plates 6mm2 Grey
      2002-1291
End Plates 2.5mm2 Grey
  2004-1291
End Plates 4mm2 Grey
  2006-1291
End Plates 6mm2 Grey
  2010-1291
End Plates 10mm2 Grey
  2016-1291
End Plates 16mm2 Grey
