WIRING ACCESSORIES Caravan Hook-Ups
Classic Hook-Up Pedestal
This touring hook-up pedestal is the world’s most popular utility pedestal with now well over 175,000 sold globally. It is specifically designed for use on touring caravan and camping sites.
• 16A IP44 interlock sockets
• 1, 2, 3 and 4way versions available
• MID compliant kWh metering & pre-paid Smartcard
metering options
• Built-in overload and 30mA fault current protection
• Photocell controlled LED amenity lighting
• Built-in cable terminals
• Hot-dipped galvanised steel internal chassis
• Aluminium composite external shell
• Segregated electric, water & lighting compartments
• Optional 1⁄2” water tap available
• IK10 impact resistant enclosure
• IP rated and UV stabilised
• Fire retardant
• Corrosion resistant
• Surface or root mountable
rolec
Quantum Hook-Up Pedestal
A stylish and sophisticated hook-up pedestal, providing caravan and holiday parks with a modern, anodised aluminium hook-up solution for their visitors to use. With its unique LED louvered lighting head, the Quantum presents an attractive solution for park destinations across the UK.
• 16A IP44 interlock sockets
• 1, 2, 3 and 4way versions available
• MID compliant kWh metering & pre-paid Smartcard
metering options
• Built-in overload and 30mA fault current protection
• Photocell controlled LED amenity lighting
• Built-in cable terminals
• Hot-dipped galvanised steel internal chassis
• Heavy duty aluminum body & panels
• Fully segregated electric, water & lighting compartments
• IK10 impact rating
• IP rated and UV stabilised
• Fire retardant
• Corrosion resistant
• Surface or root mountable
1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO, 10 x 1W LED Illumination, Non-Metered
2 x 16A 230V IP44 Interlock Sockets, 2 x 16A 30mA RCBOs, 10 x 1W LED Illumination, Non-Metered
3 x 16A 230V IP44 Interlock Sockets, 3 x 16A 30mA RCBOs, 10 x 1W LED Illumination, Non-Metered
4 x 16A 230V IP44 Interlock Sockets, 4 x 16A 30mA RCBOs, 10 x 1W LED Illumination, Non-Metered
1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO, 10 x 1W LED Illumination, 1 x kWh Mini Meter
2 x 16A 230V IP44 Interlock Sockets, 2 x 16A 30mA RCBOs, 10 x 1W LED Illumination, 2 x kWh Mini Meters
3 x 16A 230V IP44 Interlock Sockets, 3 x 16A 30mA RCBOs, 10 x 1W LED Illumination, 3 x kWh Mini Meters
4 x 16A 230V IP44 Interlock Sockets, 4 x 16A 30mA RCBOs, 10 x 1W LED Illumination, 4 x kWh Mini Meters Quantum Galvanised Steel Ground Mounting Base
Other options available. Ask in branch for details
1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO
1 x 32A 230V IP44 Interlock Socket, 1 x 32A 30mA RCBO
2 x 16A 230V IP44 Interlock Sockets, 2 x 16A 30mA RCBOs
2 x 32A 230V IP44 Interlock Sockets, 2 x 32A 30mA RCBOs
3 x 16A 230V IP44 Interlock Sockets, 3 x 16A 30mA RCBOs
4 x 16A 230V IP44 Interlock Sockets, 4 x 16A 30mA RCBOs
4 x 32A 230V IP44 Interlock Sockets, 4 x 32A 30mA RCBOs
1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO, 1 x 45A kWh Meter 1 x 32A 230V IP44 Interlock Socket, 1 x 32A 30mA RCBO, 1 x 45A kWh Meter 2 x 16A 230V IP44 Interlock Sockets, 2 x 16A 30mA RCBOs, 2 x 45A kWh Meters 2 x 32A 230V IP44 Interlock Sockets, 2 x 32A 30mA RCBOs, 2 x 45A kWh Meters 3 x 16A 230V IP44 Interlock Sockets, 3 x 16A 30mA RCBOs, 3 x 45A kWh Meters 4 x 16A 230V IP44 Interlock Sockets, 4 x 16A 30mA RCBOs, 4 x 45A kWh Meters 1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO, 1 x Smartcard Meter 1 x 32A 230V IP44 Interlock Socket, 1 x 32A 30mA RCBO, 1 x Smartcard Meter 1350mm Galvanised Steel Post to Suit Small & Large Hook-Up Enclosures
Part No.
Description
Part No.
Description
LSQR0010i
LSAI0010i
1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO, 4 x 1W LED Illumination, Non-Metered
LSQR0020i
LSAI0020i
2 x 16A 230V IP44 Interlock Sockets, 2 x 16A 30mA RCBOs, 4 x 1W LED Illumination, Non-Metered
LSQR0030i
LSAI0030i
3 x 16A 230V IP44 Interlock Sockets, 3 x 16A 30mA RCBOs, 4 x 1W LED Illumination, Non-Metered
LSQR0040i
LSAI0040i
4 x 16A 230V IP44 Interlock Sockets, 4 x 16A 30mA RCBOs, 4 x 1W LED Illumination, Non-Metered
LSQR0010i /KWH
LSAI0010i/KWH
LSQR0020i /KWH
LSAI0020i/KWH
1 x 16A 230V IP44 Interlock Socket, 1 x 16A 30mA RCBO, 4 x 1W LED Illumination, 1 x kWh Mini Meter
2 x 16A 230V IP44 Interlock Sockets, 2 x 16A 30mA RCBOs, 4 x 1W LED Illumination, 2 x kWh Mini Meters
LSQR0030i /KWH
LSAI0030i/KWH
3 x 16A 230V IP44 Interlock Sockets, 3 x 16A 30mA RCBOs, 4 x 1W LED Illumination, 3 x kWh Mini Meters
LSQR0040i /KWH
LSAI0040i/KWH
4 x 16A 230V IP44 Interlock Sockets, 4 x 16A 30mA RCBOs, 4 x 1W LED Illumination, 4 x kWh Mini Meters
GMQR0010
GMCP0010
Classic Standard Galvanised Steel Ground Mounting Base
Other options available. Ask in branch for details
Touring, Static & Camping Hook-Up Units
These cost effective and hard-wearing hook-up units
are suitable for all caravan and holiday parks. With IP44 interlock sockets, these hook-up units ensure a safe and secure electrical connection(s). Available in non-metered, metered and smartcard metered versions.
• IP44 interlock sockets
• 16A to 32A versions available
• IP65 weatherproof enclosure
• Built-in overload & 30mA fault current protection
• Built-in cable terminals
• Optional photocell kit to control park lighting
• Switchgear access flap
• IP Rated, UV stabilised
& fire retardant
GENERATE VALUE
Other options available. Ask in branch for details
Part No.
Description
LSAA0010i
LSAA0030i
LSAH0040i
LSAH0045i
LSAH0050i
LSAH0060i
LSAH0065i
LSAB0010i
LSAB0030i
LSAC0010i
LSAC0030i
LSAH0090i
LSAH0100i
LSAB0090i
LSAB0110i
LSAF0060
