P. 261

                    WIRING ACCESSORIES
EV Charging
ChargeCheck:EV Testing Unit
Designed to carry out a full range of tests on most 3.6kW (16A) and 7.2kW (32A) single phase, Mode 3, Type 1 (J1772) and Type 2 (IEC 62196) EV chargepoints.
• Tests both Type 1 (J1772) and Type 2 (IEC 62196) EV charging points
• Test the Mode 3 communication
unit by simulating the communication protocol of an electric vehicle
• Includes adapter cable and carry bag
O-Pen:EV Consumer Unit
Designed specifically to provide a safe and compliant alternative to an Earth electrode/rod when installing 1 x single phase chargepoint to the existing PME earthing facility.
• Continually monitors the electrical system and in the event of a fault automatically disconnects all poles including the earth conductor (CPC)
• IP40 rated Powder Coated metal consumer unit.
• Protect all types of 16A &
32A EV chargepoints.
• Built-in Type A RCBO
providing overload & 30mA fault current protection
• Built-in electrical contactor
• No Earth Electrode/Rod
     EVPP0145
Required
      Part No.
Description
Part No.
    EVTU0018
ChargeCheck:EV with adapter cable & carry bag
EVIN0050
Description
  20A 230V Monitoring & Protection Consumer Unit 40A 230V Monitoring & Protection Consumer Unit
    Replacement Lead, 1m 32A Type 1 to Type 2
EVIN0060
    EV Accessories
EV CHARGE POINT SIGNAGE • Highlight your EV charging facility with an aluminium screen printed EV charging
station sign
EV CHARGING CABLES
• Plug to plug Mode 3 EV
charging cables to suit every EV
and PHEV on the market
• 5m & 10m versions available
• Impact resistant ‘run over’
proof
• IP54 rated
• 10,000 mating cycles
• Charging cable carry bags
Other options available. Ask in branch for details
GENERATE VALUE
EV CHARGE POINT BARRIERS
• Galvanised steel
powder coated charging pedestal barriers
• Root or surface mounted
            Part No.
Description
Part No.
  EVPS0010
EVPS0020
Aluminium EV A4 landscape parking sign
EVCB0020
Description
  Root mount protection barrier (48mm) Surface bolted protection barrier (48mm)
   Aluminium EV A5 landscape parking sign
EVCB0040
       PEDESTAL GROUND MOUNTING BASES • Hot dipped galvanised steel
• Ideal for strong, stable root mounting
     Part No.
Description
   EVPP0160
Type 2 to Type 1 32A (5m)
  EVPP0100
Type 2 to Type 2 32A (5m)
   Part No.
Description
  EVPP0107
Type 2 to Type 2 32A (10m)
   EVPP0320
EV charging lead carrying bag
GMCP0010
BasicCharge:EV Ground Mounting Base Quantum:EV Ground Mounting Base AutoCharge:EV Ground Mounting Base
  EVPP0105
Type 2 to Type 2 3 phase 32A (5m)
  GMQR0010
    GMPG0010
     Together we
261
