P. 273

                    SWITCHGEAR & DISTRIBUTION Consumer Units
Consumer Units
    Main Switched Board
Dual RCD Board - Unpopulated AC Type
luceco BG british general
Part No. Description
  CFUSW07
 9 Module 7 Way with 100A Switch
 CFUSW10
 12 Module 10 Way with 100A Switch
 CFUSW14
  16 Module 14 Way with 100A Switch
 CFUSW17
 19 Module 17 Way with 100A Switch
 CFUSW20
 22 Module 20 Way with 100A Switch
  Part No. Description
  CFUD6606
 12 MOD 6 Way 100A SW 2 63A 30mA RCD
 CFUD6610
  16 MOD 10 Way 100A SW 2 63A 30mA RCD
 CFUD6613
 19 MOD 13 Way 100A SW 2 63A 30mA RCD
 CFUD6616
 22 MOD 16 Way 100A SW 2 63A 30mA RCD
     RCD Incomer Board AC Type
Dual RCD Board - Unpopulated A Type
Part No. Description
  CFURSW807
 9 Module 7 Way with 80A 30mA RCD
 CFURSW810
 12 Module 10 Way with 80A 30mA RCD
 CFURSW814
 16 Module 14 Way with 80A 30mA RCD
 CFURSW817
  19 Module 17 Way with 80A 30mA RCD
 CFURSW820
 22 Module 20 Way with 80A 30mA RCD
  Part No. Description
  CFUD6606A
  6 WAY 100A Switch, 2 x 63A 30mA RCD
 CFUD6610A
10 Way Unpopulated with 2 x 63A Type A 30mA RCD 100A Main Switch
 CFUD6613A
  13 way with 10A switch & 2x63A 30mA RCD
 CFUD6616A
 16 Way Unpopulated with 2 x 63A Type A 30mA RCD 100A Main Switch
     RCD Incomer A Type
GENERATE VALUE
Populated Dual RCD A Type
Part No. Description
  CFURSW807A
 CU 7W 1X 80A A RCD UPOPEN
 CFURSW810A
 CU 10W 1X 80A A RCD UPOPEN
 CFURSW814A
 CU 14W 1X 80A A RCD UPOPEN
 CFURSW817A
  CU 17W 1X 80A A RCD UPOPEN
 CFURSW820A
 CU 20W 1X 80A A RCD UPOPEN
  Part No. Description
  CFUDP16606
 6 Way with 100A Switch, 2x 63A 30mA RCD’s & 6x MCBs
 CFUDP16610
 10 Way with 100A Switch, 2x 63A 30mA RCD’s & 10x MCBs
 CFUDP16613
  13 Way with 10A Switch & 2x63A 30mA RCD
 CFUDP16616
 16 Way with 100A Switch, 2x 63A 30mA RCD’s & 12x MCBs
     Together we
273
