P. 277

                    SWITCHGEAR & DISTRIBUTION Metal Enclosures
4 Way Enclosure
Accepts 4 one module products 1 integral neutral bar
8 Way Enclosure
• Accepts 8 one module products • 1 integral neutral bar
12 Way Enclosure
• Accepts 8 one module products
• 2 integral neutral bars fitted with links
     • •
Circpro MK
distribution units, consumer units
   Part No. Description
Part No. Description
            Y5608SMET 8 way enclosure
Y5612SMET 12 way enclosure
  Y5604SMET 4 way enclosure
   Part No. Description
21 Way Enclosure
• Accepts 8 one module products
• 3 integral neutral bars fitted with links
  • •
16 Way Enclosure
Accepts 8 one module products
3 integral neutral bars fitted with links
  Part No. Description
         Y5616SMET 16 way enclosure
Y5621SMET 21 way enclosure
     • •
4 Way Enclosure with 100A Switch
Fitted with 100A switch Accepts 2 one module products
12 Way Enclosure with 100A Switch
• Fitted with 100A switch
• Accepts 10 one module products
   Part No. Description
8 Way Enclosure with 100A Switch
• Fitted with 100A switch
• Accepts 6 one module products
 Part No. Description
Part No. Description
        Y5712SMET 12 way enclosure with 100A switch
     Y5704SMET 4 way enclosure with 100A switch
Y5708SMET 8 way enclosure with 100A switch
     • •
16 Way Enclosure with 100A Switch
Fitted with 100A switch
Accepts 14 one module products
 Part No. Description
21 Way Enclosure with 100A Switch
• Fitted with 100A switch
• Accepts 19 one module products
 Part No. Description
         Y5716SMET 16 way enclosure with 100A switch
Y5721SMET 21 way enclosure with 100A switch
   Together we
277
GENERATE VALUE
Part No. Description
