P. 281

                    SWITCHGEAR & DISTRIBUTION
Wiring Devices
RCCBs
• Positive status indication
• 230V operating voltage
• 50mm cable capacity
• 10kA breaking capacity
• DIN Rail mounted
  Part No. Description
  H6325S RCCB 25A 230V 10mA Type AC 2 module 2P
 H7825S RCCB 25A 230V 30mA Type AC 2 module 2P
 H6125S RCCB 25A 230V 100mA Type AC 2 module 2P
 H7840S RCCB 40A 230V 30mA Type AC 2 module 2P
 H6140S RCCB 40A 230V 100mA Type AC 2 module 2P
 H7860S RCCB 63A 230V 30mA Type AC 2 module 2P
 H6160S RCCB 63A 230V 100mA Type AC 2 module 2P
 H7880S RCCB 80A 230V 30mA Type AC 2 module 2P
 H6180S RCCB 80A 230V 100mA Type AC 2 module 2P
 H5880S RCCB 80A 230V 300mA Type AC 2 module 2P
 H7800S RCCB 100A 230V 30mA Type AC 2 module 2P
 H6100S RCCB 100A 230V 100mA Type AC 2 module 2P
 H5800S RCCB 100A 230V 300mA Type AC 2 module 2P
 H5325S RCCB 25A 230V 10mA Type A 2 module 2P
 H5625S RCCB 25A 230V 30mA Type A 2 module 2P
 H5725S RCCB 25A 230V 100mA Type A 2 module 2P
 H9325S RCCB 25A 230V 300mA Type A 2 module 2P
 H5640S RCCB 40A 230V 30mA Type A 2 module 2P
 H5740S RCCB 40A 230V 100mA Type A 2 module 2P
 H5660S RCCB 63A 230V 30mA Type A 2 module 2P
 H5760S RCCB 63A 230V 100mA Type A 2 module 2P
 H5680S RCCB 80A 230V 30mA Type A 2 module 2P
 H5780S RCCB 80A 230V 100mA Type A 2 module 2P
 H9380S RCCB 80A 230V 300mA Type A 2 module 2P
 H5600S RCCB 100A 230V 30mA Type A 2 module 2P
 H5700S RCCB 100A 230V 100mA Type A 2 module 2P
 H9300S RCCB 100A 230V 300mA Type A 2 module 2P
 H6900S RCCB 100A 100mA Type A/S time delay 2P
     MCB Blank     Busbar
Part No. Description
H6100S
H6900S
  • Single module
• Designed to prevent accidental
access to live parts
• DIN Rail mounted
• 5+5 split load busbar • Self-configuration
 Part No. Description
   H5511S 11 way busbar
    H5544S MCB blank to fill unused modules
Busbar     Busbar Cover
• Self-configuration
GENERATE VALUE
• Suitable for 11 and 20 way busbar
• To prevent accidental access to live parts
  Part No. Description
 Part No. Description
   HAX26S Busbar cover
    H5590S 21 way busbar
 Together we
281
