                    SWITCHGEAR & DISTRIBUTION Defender 1.0 Consumer Units
   Defender 1 Consumer U
• A comprehensive range of single phase consumer units compliant with BS7671
• 18th Edition Wiring Regulations
• Tested in accordance to BS EN 61439-3
• A modern sleek design suitable for all installations
• Up to 22 module board as standard; combine boards to increase number of outgoing ways
• Maximum cable space and extensive number of cable entry points allowing easy installation
• Degree of protection IP4X
• Flexible board configuration to enable optimal
combination of RCD, MCB and RCBO use • Pre-populated configurations available • Secure hinge design
• Locking kits available
   Surface Mounted Flexible High Integrity Split Load Dual RCD Consumer Units
80A Rated Consumer Units
Switch Disconnect Incomer Consumer Units
            Without SPD
With SPD Fitted
Description
 DDS08188AMS
    8 Way ISO Incomer + 2 RCD Class A
 DDS10188AMS
DDS10188ASPMS
10 Way ISO Incomer + 2 RCD Class A
 DDS12188AMS
 DDS12188ASPMS
 12 Way ISO Incomer + 2 RCD Class A
 DDS14188AMS
 DDS14188ASPMS
 14 Way ISO Incomer + 2 RCD Class A
 DDS16188AMS
  16 Way ISO Incomer + 2 RCD Class A
 Populated
    Description
 DDS08188AMS-P01
8WayISOIncomer+2RCDClassA+8MCB
 DDS10188AMS-P01
 DDS10188ASPMS-P01
 10WayISOIncomer+2RCDClassA+10MCB
 DDS12188AMS-P01
 DDS12188ASPMS-P01
 12WayISOIncomer+2RCDClassA+10MCB
 DDS14188AMS-P01
  DDS14188ASPMS-P01
  14WayISOIncomer+2RCDClassA+10MCB
 DDS16188AMS-P01
  16WayISOIncomer+2RCDClassA+10MCB
   Without SPD With SPD Fitted Description
   DD006SPMS
  0 Way 63A ISO Incomer + SPD
 DD026MS
2 Way 63A ISO Incomer
 DD041MS
 DD041SPMS
 4 Way 100A ISO Incomer
 DD061MS
  6 Way 100A ISO Incomer
  DD081SPMS
 8 Way 100A ISO Incomer + SPD
 DD101MS
  DD101SPMS
  10 Way 100A ISO Incomer
 DD121MS
DD121SPMS
12 Way 100A ISO Incomer
 DD141MS
 DD141SPMS
 14 Way 100A ISO Incomer
 DD161MS
 DD161SPMS
 16 Way 100A ISO Incomer
 DD181MS
  DD181SPMS
  18 Way 100A ISO Incomer
 DD201MS
  20 Way 100A ISO Incomer
     63A Rated Consumer Units
RCD Incomer Consumer Units
GENERATE VALUE
Garage Units
MCB, eRCBO, Blank & Surge Kit
  Part No.
Description
  DDS08166AMS
8 Way ISO Incomer + 2 RCD Class A
  DDS10166AMS
10 Way ISO Incomer + 2 RCD Class A
  Populated Description
   DR026AMS-P01 Garage Unit 63A RCD Class A + 16A MCB + 6A MCB
   DDS12166AMS
 Populated
DDS06166AMS-P01 DDS10166AMS-P01
12 Way ISO Incomer + 2 RCD Class A
         Populated Description
 CPB0603B to CPB0640B
 3A - 40A 6kA Curve B SP MCB
 CPB0650B & CPB0663B
  50A - 63A 4.5kA Curve B SP MCB
 CCPBR0606AB to CCPBR0650AB
6A - 50A 6kA Class A Curve B SP Compact RCBO
 CPBBL
  MCB Blank
 T2C4011KIT
 Surge 40KA 1+1 Protection Retro Fit Kit
  Part No. Description
Description
6 Way ISO Incomer + 2 RCD Class A + 6 MCB 10 Way ISO Incomer + 2 RCD Class A + 10 MCB
         DR026AMS
2 Way 63A RCD Class A Incomer
  DR048AMS
4 Way 80A RCD Class A Incomer
  DR068AMS
6 Way 80A RCD Class A Incomer
