P. 288

                    SWITCHGEAR & DISTRIBUTION RCBOs, Surge Protection Kits & Consumer Unit Accessories
RCBOs Type A, B Curve
Consumer Unit Accessories
Consumer Unit Door Lock
• Lock secures front cover to prevent unauthorised access to circuits
• 2-year guarantee
Circuit Protection Label Sheet
• Allows individual circuits to be identified
• 2-year guarantee
Consumer Unit Oval Knockout Grommet
• Insulates knockout edges
• 2-year guarantee
MCB Locks
• Prevents unauthorised access to circuits in accordance with safe isolation procedures
• 2-year guarantee
Meter Tail Clamp
• Secures meter tails in place and prevents any strain on the mains switch
• 2-year guarantee
      Part No. Description
   B1709 Consumer Unit Blanking Cap (PK 10)
 Part No. Description
   B1703 Consumer Unit Door Lock
  • Single Pole, Type A RCD, B Curve, Residual Current Circuit Breaker with overload protection
• 30mA tripping current and provides protection against earth fault, leakage current, short circuit and overloading
• 1 module width
• 35mm DIN rail mounting
• Terminals have an automatic blanking plate,
preventing incorrect termination
• Can be removed without removing the busbar
• 3-year guarantee
• IEC 61009-1
Consumer Unit Blanking Caps
• Allows hole in enclosure cover to be covered if lock is not used or removed
• 2-year guarantee
Din Rail Mounted Blank Module
• Used to cover unused module spaces
• 1 module width • 35mm DIN rail
mounting
• 2-year guarantee
Contactors
• Used to switch a higher power circuit on or off from a lower power circuit
• Double Pole
• 20A 1 module width, 40A 2 module width
• 35mm DIN rail mounting
• 2-year guarantee
Live Bus Bars
• Spare busbars
• Used to create a split load consumer unit
arrangement
• 2-year guarantee
GENERATE VALUE
 Part No. Description
   B1711 Din Rail Mounted Blank Module
 Part No. Description
   B1704 Circuit Protection Label Sheet
   Part No. Description
     B1406
6A Type A RCD B Curve RCBO
  B1416
16A Type A RCD B Curve RCBO
   B1420
20A Type A RCD B Curve RCBO
  B1432
32A Type A RCD B Curve RCBO
  B1440
Surge Protection Device Kit
  Part No. Description
   B1706 Consumer Unit Oval Knockout Grommet
  Part No. Description
  B1713
  20A Contactor
 B1714
 40A Contactor
  • Kit includes: 1 x Type 2 Surge Protection Device, 1 x 32A, Type B Curve, 10kA MCB and connection cables
• Suitable for single phase TNS and TT earthing systems
• Provides protection against voltage transients and surges from lightning and switching sources
• Includes visual indication window for normal operation or fault status
• 2 module (SPD) plus 1 module (MCB) width
• 35mm DIN rail mounting
• 3-year guarantee
• BS EN 61643-11
 Part No. Description
   B1707 MCB Lock (PK 5)
   Part No. Description
  B172108
  8 Way Live Bus Bar (Pk 5)
 B172120
 20 Way Live Bus Bar (Pk 5)
  Part No. Description
40A Type A RCD B Curve RCBO
  Part No. Description
   B1708 Meter Tail Clamp
     B1951 Surge Protection Device Kit
