P. 287

                    SWITCHGEAR & DISTRIBUTION
Consumer Units, Enclosures & Devices
Mains Switch Consumer Units
deta
Shower Enclosures RCDs
        • Surface mounted, steel enclosure with curved lockable lid (lock supplied separately)
• Populated with 100A mains switch
• 10 or 14 Free Ways
• Large oval cable entries on rear, supplied with
grommets with multiple cut-outs
• Raised DIN rail to allow cables to pass underneath
• Floating busbar with pre-fitted cover for
greater installation flexibility
• Supplied with circuit identification label sheet
• 10-year guarantee
• BS EN 61439-3, 18 Edition IET Wiring Regulations
High Integrity Consumer Units
• Surface mounted, steel enclosure with curved lid
• Populated with 1 x 63A 30mA Type AC RCD and 1 x 50A MCB
• Raised DIN rail to allow cables to pass underneath
• IP2X rating for protection from objects greater than 12.5mm
• 10-year guarantee
• BS EN 61439-3, IET Wiring Regulations
• Double Pole, Type A Residual Current Device
• 30mA tripping current and provides protection
against earth leakage current
• Provides protection for general purpose
applications as well as equipment incorporating electronic components creating residual pulsating DC current up to 6mA
• 2 module width
• 35mm DIN rail mounting
• Terminals have an automatic blanking plate,
preventing incorrect termination • 3-year guarantee
• IEC 61008-1
MCBs
• SinglePole,TypeBCurveMiniatureCircuitBreaker
• Rated at 6kA
• 1 module width
• 35mm DIN rail mounting
• Terminals have an automatic blanking plate, preventing incorrect termination
• Can be removed without removing the busbar
• 10-year guarantee
• IEC 60898-1
Part No. Description
   B1622 100A 30mA Type A RCD
 Part No. Description
  BV1092 Shower Consumer Unit 3 Module IP2X
Garage Enclosures
 • Surface mounted, steel enclosure with curved lid
• Populated with 1 x 63A 30mA Type AC RCD, 1 x 32A MCB and 1 x 6A MCB
• RaisedDINrailtoallowcablestopass underneath
• IP2X rating for protection from solid objects larger than 12.5mm
• IP65 rating protects against dust and low pressure jets of water
• 10-year guarantee
• BS EN 61439-3, IET Wiring Regulations
Part No. Description
  BV1081
  Garage Consumer Unit 4 Module IP2X
 BV1086
 Garage Consumer Unit 4 Module IP65
  Part No. Description
  BV0003
  12M 10W 100A Mains Switch Consumer Unit
 BV0004
 16M 14W 100A Mains Switch Consumer Unit
        Part No. Description
  B1206
 6A 6kA Type B Curve MCB
 B1206C
 6A 6kA Type C Curve MCB
 B1210
  10A 6kA Type B Curve MCB
 B1210C
10A 6kA Type C Curve MCB
 B1216
 16A 6kA Type B Curve MCB
 B1216C
 16A 6kA Type C Curve MCB
 B1220
  20A 6kA Type B Curve MCB
 B1220C
20A 6kA Type C Curve MCB
 B1232
 32A 6kA Type B Curve MCB
 B1232C
 32A 6kA Type C Curve MCB
 B1240
  40A 6kA Type B Curve MCB
 B1240C
40A 6kA Type C Curve MCB
 B1245
 45A 6kA Type B Curve MCB
 B1245C
 45A 6kA Type C Curve MCB
 B1250
  50A 6kA Type B Curve MCB
 B1250C
50A 6kA Type C Curve MCB
 B1263
  63A 6kA Type B Curve MCB
 B1263C
 63A 6kA Type C Curve MCB
  • Surface mounted, steel enclosure with curved lockable lid (lock supplied separately)
• Pre-wired with 100A DP mains switch and 2 x 80A 30mA, Type A RCDs
• 10/12/16 Free Ways
• Large oval cable entries on rear, supplied with
grommets with multiple cut-outs
• RaisedDINrailtoallowcablestopassunderneath
• Floating busbar with pre-fitted cover for greater
installation flexibility
• Supplied with circuit identification label sheet
and blank modules
• Supplied with 3 neutral floating busbars for
greater installation flexibility
• 10-year guarantee
• BS EN 61439-3, 18 Edition IET Wiring Regulations
GENERATE VALUE
287
 Part No. Description
       BV5034
16M 10W High Integrity Consumer Unit
  BV5035
18M 12W High Integrity Consumer Unit
  BV5036
22M 16W High Integrity Consumer Unit
