P. 286

                    SWITCHGEAR & DISTRIBUTION Circuit Protection
    B Boards
• 4 to 16 triple pole ways
• 4 pole RCD’s n 125A busbar
• Removable pan assembly
• Enclosure IP 4X n Tin plated copper
busbar
• RAL 9016 textured finish
• Door locking feature
• Removable top & bottom
• 4 pole 125A isolator
• Single pole conversion kit gland plates
      IP66 Enclosed Switches
• Enclosed Disconnect BS EN 60947-3 • Fuse Switches BS EN 60269/BS 88
• Terminal shrouds to IP20 line side • Disconnectable solid neutral link
• Hinged door
• Red/Yellow handles available on request • Auxiliary contacts available
• Padlockable using up to 3 padlocks
• Door interlocked padlockable handle as
standard
• IP66 rated metal enclosures • Paint finish RAL 7032
• Bottom mounted gland plate
• Tested to IEC 62208
• Galvanised steel
• Powder coated – RAL 7032
• Injected polyurethane gasket
• Bottom gland plate
• IP66, highest ingress protection &
Tested as per IEC 60529
• IK10, highest mechanical impact
protection & Tested as per IEC 62262
• C/W mounting plate – galvanised steel • Fitted earth strip
• Material thickness 1.2mm - 1.5mm
• Corrosion Resistance = 1000 Hours salt
spray test ASTM B117
GENERATE VALUE
  IP66 Steel Enclosures
  286
