P. 290

                    SWITCHGEAR & DISTRIBUTION
Memshield 3 MCB Distribution Boards and Enclosures
125A SPN, Type A Distribution Boards Incoming Devices For SPN, Type
• When more than 16 SP ways are required, see our A Distribution Boards
     TPN board ranges, complete with single phase
kit options
• Enclosure degree of protection IP3X
(wall-mounted)
• Incoming devices supplied separate to distribution board
   Part No.
Description
Rating (A)
Total no. of outgoing ways
EAM4
 4 way SPN, type A distribution board
 125
 4
 EAM7
7 way SPN, type A distribution board
125
7
 EAM10
 10 way SPN, type A distribution board
 125
 10
 EAM13
  13 way SPN, type A distribution board
  125
  13
 EAM16
 16 way SPN, type A distribution board
 125
 16
  Part No.
Description
Rating (A)
Poles
Sensitivity (mA)
EAMS1251N
 Switch-disconnector
 125
 SPSN
-
 EAMS100HE
RCCB incoming device for SPN, type A distribution board
90
1P+N
30
 EAMS100ME
 RCCB incoming device for SPN, type A distribution board
 90
1P+N
 100
 EAMS100LE
  RCCB incoming device for SPN, type A distribution board
  90
 1P+N
 300
 EAMBT1002
 Direct connection kit for SPN, type A distribution board
 100
 1P+N
-
      Metered SPN, Type A Distribution Boards & Standard Meter Packs
 • Type A SPN boards, fitted with multifunction meters, can display; Amps, kW, kWh, kVar and kVarh pulsed output etc.
• Split load versions utilise a two channel meter, feeding two independent busbars and groups of MCB/RCBOs
• Split load versions provide independent monitoring of “Power” and “Lighting” loads and total load.
• Aids compliance with Part L2 of the building regulations (England & Wales and Section 6 Scotland)
• Enclosure degree of protection IP3X (wall-mounted)
  Part No.
Description
Rating (A)
Total no. of outgoing ways
Installed meter characteristics
EAMMP65
 Meterpack for SPN, type A distribution boards
 65
 -
 Pulsed output, kWh
 EAM9M
 9 way SPN, type A distribution board
 65
 9
 Pulsed output, kWh
 EAM9MB
9 way SPN, type A distribution board
65
9
Modbus
 EAM12M
 12 way SPN, type A distribution board
 65
 12
 Pulsed output, kWh
 EAM12MB
 12 way SPN, type A distribution board
 65
 12
 Modbus
 EAMSL93M
 Split metered SPN, type A distribution board
 100
 9+ 3
 Pulsed output, kWh
 EAMSL93MB
  Split metered SPN, type A distribution board
  100
  9+ 3
  Modbus
 EAMSL66M
 Split metered SPN, type A distribution board
 100
 6+ 6
 Pulsed output, kWh
 EAMSL66MB
 Split metered SPN, type A distribution board
 100
 6+ 6
 Modbus
    Metered SPN, Type A Distribution Boards & Standard Meter Packs
   Part No. Description
EAMMP65 Meterpack for SPN, type A distribution boards
