P. 292

                    SWITCHGEAR & DISTRIBUTION Distribution Boards
250A TPN, Type B High Load Distribution Board
• These boards include 2 TPN outgoing ways for • IP4X
   27mm MCB (upto 125A)
• Adequate integral cabling space means that
no extension box is required
• Fitted with door lock as standard
Part No.
Description
Rating (A)
Total no. of 18mm TP Outgoing Ways (63A Max)
Total no. of 27mm TP Outgoing Ways (125A Max)
Total
no. of Outgoing Ways
EBM22H
 2 Way TPN
 20
 0
 2
 2
 EBM62H
6 Way TPN
25
4
2
6
 EBM82H
 8 Way TPN
 25
 6
 2
 8
 EBM122H
  12 Way TPN
  25
  10
  2
  12
 EBM182H
 18 Way TPN
 25
 16
 2
 18
 EBM242H
 24 Way TPN
 25
 22
 2
 24
    Split Metered Power And Lighting Board – 200A TPN, Type B
   • Includes factory fitted 200A switch disconnector and two channel meter
• Adequate integral cabling space means that no extension box is required
• IP4X
• Fitted with door lock as standard
• Single phasing kit included to be used if
required
Part No.
   EBMSL642MPMB
Split Metered TPN
200
6+4
Modbus + Pulsed Output, kWh
     EBMSL862MPMB
Split Metered TPN
200
8+6
Modbus + Pulsed Output, kWh
     EBMSL1082MPMB
Split Metered TPN
200
10+8
Modbus + Pulsed Output, kWh
     EBMSL14102MPMB
RCBOs
Split Metered TPN
200
14+10
Modbus + Pulsed Output, kWh
      Outgoing Devices, RCBOs Single Pole
 • Eaton’s range of residual current circuit breakers with integral overload protection (RCBOs), are manufactured to IEC/ EN 61009 and meet the latest European and international standards
Trip Type C - 30mA Sensitivity
Part No.
Description
Rating (A)
Trip Type
Sensitivity (mA)
EMCH106R30C
 RCBO 6A 10kA type C SP
 6
 C
 30
 EMCH110R30C
RCBO 10A 10kA type C SP
10
C
30
 EMCH116R30C
 RCBO 16A 10kA type C SP
 16
 C
 30
 EMCH120R30C
 RCBO 20A 10kA type C SP
 20
 C
 30
 EMCH125R30C
 RCBO 25A 10kA type C SP
 25
 C
 30
 EMCH132R30C
  RCBO 32A 10kA type C SP
  32
  C
  30
 EMCH140R30C
 RCBO 40A 10kA type C SP
 40
 C
 30
 EMCH145R30C
 RCBO 45A 10kA type C SP
 45
 C
 30
     Trip Type B - 30mA Sensitivity
Part No.
Description
Rating (A)
Trip Type
Sensitivity (mA)
EMBH106R30C
 RCBO 6A 10kA type B SP
 6
 B
 30
 EMBH110R30C
 RCBO 10A 10kA type B SP
 10
 B
 30
 EMBH116R30C
RCBO 16A 10kA type B SP
16
B
30
 EMBH120R30C
 RCBO 20A 10kA type B SP
 20
 B
 30
 EMBH132R30C
 RCBO 32A 10kA type B SP
 32
 B
 30
 EMBH140R30C
  RCBO 40A 10kA type B SP
  40
  B
  30
 EMBH145R30C
 RCBO 45A 10kA type B SP
 45
 B
 30
     292
Together we
Description
Rating (A)
Total no. of Outgoing Ways
Installed Meter Characteristics
GENERATE VALUE
