                    SWITCHGEAR & DISTRIBUTION Memshield 3 MCB Distribution Boards and Enclosures
Outgoing Devices – MCBs – 10/15kA, Three Pole
• Trip types B, C and D
• Dual rated, 10kA to IEC 60898 and 15kA to IEC 60947-2
  Trip type B Part No.
Trip type C Part No.
Trip type D Part No.
Description
Rating (A) (total load)
Width (mm)
Short circuit rating (kA)
EMBH301
 EMCH301
 EMDH301
 Miniature circuit breaker
 1
 54
 10 /15
 EMBH302
EMCH302
EMDH302
Miniature circuit breaker
2
54
10 /15
 EMBH304
 EMCH304
 EMDH304
 Miniature circuit breaker
 4
 54
 10 /15
 EMBH306
 EMCH306
 EMDH306
 Miniature circuit breaker
 6
 54
 10 /15
 EMBH308
  EMCH308
  EMDH308
  Miniature circuit breaker
  8
  54
  10 /15
 EMBH310
EMCH310
EMDH310
Miniature circuit breaker
10
54
10 /15
 EMBH313
 EMCH313
 EMDH313
 Miniature circuit breaker
 13
 54
 10 /15
 EMBH316
 EMCH316
 EMDH316
 Miniature circuit breaker
 16
 54
 10 /15
 EMBH320
 EMCH320
 EMDH320
 Miniature circuit breaker
 20
 54
 10 /15
 EMBH325
  EMCH325
  EMDH325
  Miniature circuit breaker
  25
  54
  10 /15
 EMBH332
EMCH332
EMDH332
Miniature circuit breaker
32
54
10 /15
 EMBH340
 EMCH340
 EMDH340
 Miniature circuit breaker
 40
 54
 10 /15
 EMBH350
  EMCH350
  EMDH3501)
  Miniature circuit breaker
  50
  54
  10 /15
 EMBH363
 EMCH363
 EMDH3631)
 Miniature circuit breaker
 63
 54
 10 /15
     1) 15kA to IEC60947-2 rating only
Outgoing Devices (For 250A High Load Distribution Board Only) – MCBs, Single Pole
Outgoing Devices (For 250A High Load Distribution Board Only) – MCBS, Three Pole
Protective devices EM*S and EM*H can be added to protect the load circuits. The board can disperse a maximum current of 250A which can be split between a combination of MCBs
EM*S - 125A 27mm 3P MCB = 81mm wide EM*H - 63A 18mm 3P MCB = 54mm wide Available space on din rail = 272mm. Maximum Thermal Ratings
LUGS Incomer = 250A max
EM*S - 125A 27mm MCB = 102A max EM*H - 63A 18mm MCB = 55A max Required Load cables: Tri-Rated to BS 6231 125A MCB = 50mm2
63A MCB = 16mm2
GENERATE VALUE
295
   Trip type B Part No.
Trip type C Part No.
Trip type D Part No.
Rating current in (A)
Width (mm)
Short circuit rating (IEC/EN 60947-2)
EMBS120
 EMCS120
 EMDS120
 20
 27
 25kA
 EMBS132
EMCS132
EMDS132
32
27
25kA
 EMBS140
  EMCS140
  EMDS140
  40
  27
  25kA
 EMBS150
EMCS150
EMDS150
50
27
25kA
 EMBS163
 EMCS163
 EMDS163
 63
 27
 25kA
 EMBS180
 EMCS180
 EMDS180
 80
 27
 25kA
 EMBS1100
  EMCS1100
  EMDS1100
  100
  27
  25kA
 EMBS1125
 EMCS1125
 -
 125
 27
 25kA
     Trip type B Part No.
Trip type C Part No.
Trip type D Part No.
Rating current in (A)
Width (mm)
Short circuit rating (IEC/EN 60947-2)
EMBS320
 EMCS320
 EMDS320
 20
 81
 25kA
 EMBS332
EMCS332
EMDS332
32
81
25kA
 EMBS340
 EMCS340
 EMDS340
 40
 81
 25kA
 EMBS350
  EMCS350
  EMDS350
  50
  81
  25kA
 EMBS363
EMCS363
EMDS363
63
81
25kA
 EMBS380
 EMCS380
 EMDS380
 80
 81
 25kA
 EMBS3100
  EMCS3100
  EMDS3100
  100
  81
  25kA
 EMBS3125
 EMCS3125
 -
 125
 81
 25kA
