P. 294

                    SWITCHGEAR & DISTRIBUTION
Memshield 3 MCB Distribution Boards and Enclosures
Multi Meterpack Assemblies
Eaton’s Memshield 3 meter packs provide simple integration with matched aesthetics. Split metering for separate small power and lighting has been added to the range to meet the needs of the L2 Regulations introduced in England and Wales in 2006. The meters provide a pulsed output for kWh and display other useful parameters, including line voltage and current. Modbus versions are also available and provide remote access to additional electrical parameters.
  Part No.
Description
Rating (A)
Installed Meter, Characteristics
 EBMMPCT250
 Meterpack
 250
 Pulsed Output, kWh
 EBMMPCT250M
 Meterpack
 250
 Modbus + Pulsed Output, kWh
 EBMMPCT250MID
  Meterpack
  250
  MID certified Meter
 EBMMPSL250
Double Meterpack
250
Pulsed Output, kWh
 EBMMPSL250M
 Double Meterpack
 250
 Modbus + Pulsed Output, kWh
 EBMMPSL250MID
 Double Meterpack
 250
 MID Certified Meter
 EBMMPSL125
  Double Meterpack
  125
  Pulsed Output, kWh
 EBMMPSL125M
Double Meterpack
125
Modbus + Pulsed Output, kWh
 EBMMPSL125MID
  Double Meterpack
  125
  MID Certified Meter
 EBMMPDC120
 Meterpack
 120
 MID Certified Meter
     Part No.
Description
Rating (A) (total load)
Installed meter characteristics
EBMMPSL250DMID
 Multi meterpack - double
 250
 MID certified meter
 EBMMPSL250QM
 Multi meterpack - quad
 250
 Modbus + pulsed output
    Outgoing Devices – MCBS – 10/15kA, Single Pole
• Trip types B, C and D
• Dual rated, 10kA to IEC 60898 and 15kA to IEC 60947-2
  Trip type B Part No.
Trip type C Part No.
Trip type D Part No.
Description
Rating (A) (total load)
Width (mm)
Short circuit rating (kA)
EMBH101
 EMCH101
 EMDH101
 Miniature circuit breaker
 1
 18
 10 /15
 EMBH102
EMCH102
EMDH102
Miniature circuit breaker
2
18
10 /15
 EMBH104
 EMCH104
 EMDH104
 Miniature circuit breaker
 4
 18
 10 /15
 EMBH106
 EMCH106
 EMDH106
 Miniature circuit breaker
 6
 18
 10 /15
 EMBH108
  EMCH108
  EMDH108
  Miniature circuit breaker
  8
  18
  10 /15
 EMBH110
EMCH110
EMDH110
Miniature circuit breaker
10
18
10 /15
 EMBH113
 EMCH113
 EMDH113
 Miniature circuit breaker
 13
 18
 10 /15
 EMBH116
 EMCH116
 EMDH116
 Miniature circuit breaker
 16
 18
 10 /15
 EMBH120
  EMCH120
  EMDH120
  Miniature circuit breaker
  20
  18
  10 /15
 EMBH125
EMCH125
EMDH125
Miniature circuit breaker
25
18
10 /15
 EMBH132
 EMCH132
 EMDH132
 Miniature circuit breaker
 32
 18
 10 /15
 EMBH140
 EMCH140
 EMDH140
 Miniature circuit breaker
 40
 18
 10 /15
 EMBH150
  EMCH150
  EMDH1501)
  Miniature circuit breaker
  50
  18
  10 /15
 EMBH163
 EMCH163
 EMDH1631)
 Miniature circuit breaker
 63
 18
 10 /15
     1) 15kA to IEC60947-2 rating only
