                    SWITCHGEAR & DISTRIBUTION Panelboards
Memshield 3
MCCB Panelboards and Associated Devices
     Meter
Meter is available with pulsed and modbus outputs. Simply installed with 2 locking screws.
  Incoming Meter Enclosure
250mm high enclosure with hinged front door. Simply bolted to the top or the bottom of the panelboard.
Supply tap-off
Provision to fit tap-off to either the left and/or right hand side of the pan assembly.
Only 1 per panelboard is required but provision to fit two is an option.
    Incoming metering connection kit
This includes all copper connectors, CT, shielding and CT to meter cable. Can be top or bottom fed.
This does not include the incoming device, which has to be ordered separately.
  Incoming Device Ratings Up To 250A
• Minimum ordering requirement: panelboard + incoming device + incomer connection kit + outgoing devices + blanking plates
   Part No.
Description
Associated incoming device
Current rating (A)
No. of ways
EPBN1425
 Incoming rating up to 250A, outgoing ratings up to 160A
 NZM2 MCCB or N2 switch disconnector or direct lugs connection
 250
 4
 EPBN1625
6
 EPBN1825
  8
 EPBN11225
 12
     296
Together we
Cable extension box (when necessary)
250mm high enclosure, fitted incoming end. When incoming meter enclosure is fitted at the feed end of the 400A/630A/800A boards there is no need for a cable
