                                    297SWITCHGEAR & DISTRIBUTIONTogether we GENERATE VALUEMemshield 3 MCB Distribution Boards and EnclosuresTrip type B Part No.Trip type C Part No.Trip type D Part No.Description Rating (A) (total load)Width (mm)Short circuit rating (kA)EMBH301 EMCH301 EMDH301 Miniature circuit breaker 1 54 10 /15EMBH302 EMCH302 EMDH302 Miniature circuit breaker 2 54 10 /15EMBH304 EMCH304 EMDH304 Miniature circuit breaker 4 54 10 /15EMBH306 EMCH306 EMDH306 Miniature circuit breaker 6 54 10 /15EMBH308 EMCH308 EMDH308 Miniature circuit breaker 8 54 10 /15EMBH310 EMCH310 EMDH310 Miniature circuit breaker 10 54 10 /15EMBH313 EMCH313 EMDH313 Miniature circuit breaker 13 54 10 /15EMBH316 EMCH316 EMDH316 Miniature circuit breaker 16 54 10 /15EMBH320 EMCH320 EMDH320 Miniature circuit breaker 20 54 10 /15EMBH325 EMCH325 EMDH325 Miniature circuit breaker 25 54 10 /15EMBH332 EMCH332 EMDH332 Miniature circuit breaker 32 54 10 /15EMBH340 EMCH340 EMDH340 Miniature circuit breaker 40 54 10 /15EMBH350 EMCH350 EMDH3501) Miniature circuit breaker 50 54 10 /15EMBH363 EMCH363 EMDH3631) Miniature circuit breaker 63 54 10 /15• Trip types B, C and D• Dual rated, 10kA to IEC 60898 and 15kA to IEC 60947-2Outgoing Devices – MCBs – 10/15kA, Three Pole1) 15kA to IEC60947-2 rating onlyTrip type B Part No.Trip type C Part No.Trip type D Part No.Rating current in (A) Width (mm)Short circuit rating(IEC/EN 60947-2)EMBS120 EMCS120 EMDS120 20 27 25kAEMBS132 EMCS132 EMDS132 32 27 25kAEMBS140 EMCS140 EMDS140 40 27 25kAEMBS150 EMCS150 EMDS150 50 27 25kAEMBS163 EMCS163 EMDS163 63 27 25kAEMBS180 EMCS180 EMDS180 80 27 25kAEMBS1100 EMCS1100 EMDS1100 100 27 25kAEMBS1125 EMCS1125 - 125 27 25kAOutgoing Devices (For 250A High Load Distribution Board Only) – MCBs, Single PoleTrip type B Part No.Trip type C Part No.Trip type D Part No.Rating current in (A) Width (mm)Short circuit rating(IEC/EN 60947-2)EMBS320 EMCS320 EMDS320 20 81 25kAEMBS332 EMCS332 EMDS332 32 81 25kAEMBS340 EMCS340 EMDS340 40 81 25kAEMBS350 EMCS350 EMDS350 50 81 25kAEMBS363 EMCS363 EMDS363 63 81 25kAEMBS380 EMCS380 EMDS380 80 81 25kAEMBS3100 EMCS3100 EMDS3100 100 81 25kAEMBS3125 EMCS3125 - 125 81 25kAOutgoing Devices (For 250A High Load Distribution Board Only) – MCBS, Three PoleProtective devices EM*S and EM*H can be added to protect the load circuits. The board can disperse a maximum current of 250A which can be split between a combination of MCBs EM*S - 125A 27mm 3P MCB = 81mm wideEM*H - 63A 18mm 3P MCB = 54mm wideAvailable space on din rail = 272mm.Maximum Thermal RatingsLUGS Incomer = 250A maxEM*S - 125A 27mm MCB = 102A maxEM*H - 63A 18mm MCB = 55A maxRequired Load cables: Tri-Rated to BS 6231125A MCB = 50mm²63A MCB = 16mm²eatoneatoneaton
