                    SWITCHGEAR & DISTRIBUTION Memshield 3 MCB Distribution Boards and Enclosures
125A/250A TPN, Type B Distribution Boards
• Enclosure degree of protection IP4X (wall-mounted)
   Part No.
Description
Rating (A)
Total no. of outgoing ways
EBM41
 4 way TPN, type B distribution board
 125
 4
 EBM61
6 way TPN, type B distribution board
125
6
 EBM81
 8 way TPN, type B distribution board
 125
 8
 EBM121
 12 way TPN, type B distribution board
 125
 12
 EBM161
  16 way TPN, type B distribution board
  125
  16
 EBM122
12 way TPN, type B distribution board
125/2251)
12
 EBM182
  18 way TPN, type B distribution board
  125/2501)
  18
 EBM242
 24 way TPN, type B distribution board
 125/2501)
 24
    1) 225A/250A options – if used with cable extension box or with cable trunking. Note: Maximum loading EBM122 -225A
125A SPSN, Type B Distribution Board
• SPSN main switch disconnector fitted
• Enclosure degree of protection IP4X (wall-mounted)
   Part No.
Description
Rating (A)
Total no. of outgoing ways
 EBM121D 12 way SPSN type B distribution board 125 12
 125A Incomer Options For Type B Distribution Boards
• Incoming devices supplied separate to distribution board • Maximum Cable capacity 50mm2
   Part No.
Description
Rating (A)
Pole configuration
EBMS1253
 Switch disconnector
 125
 12
 EBMS1251N
Switch disconnector kit (including single phasing link)
125
SPSN
 EBMS1253N
 Switch disconnector
 125
 TPSN
 EBMBT2503
  Direct connection (lugs connector)
  125/250
  TP
 EBMR30
30mA RCCB1)
100
TPSN
 EBMR100
 100mA RCCB1)
 100
 TPSN
 EBMR300
  300mA RCCB1)
  100
  TPSN
 EBMR300T
 300mA RCCB with time delay
 100
 TPSN
 EBMCC1253
 Switch disconnector feeding 125A TP AC1 contactor, housed in extension box
 125
 TP
    1) Includes 50mm2 terminal adapter
