                    SWITCHGEAR & DISTRIBUTION
Memshield 3 MCB Distribution Boards and Enclosures
125A AFDD Type B TPN Distribution Board Surge Protection Device For AFDD
Distribution Board
• Includes 63A TPN type C MCB for protection and isolation
• Includes all connecting cables and fixings
Accessories for AFDD distribution board
   • Enclosure will accept Eaton 2-pole, 3 module, AFDDs
• Optional internal SPD
• Enclosure degree of protection
IP4X (wall mounted)
• Short circuit rating 10kA
eaton
    Part No.
Description
Rating (A)
Total no. of AFDD outgoing ways
EBMAFDD141
 14 way AFDD, TPN, type B distritbution board
 125
 14
 EBMAFDD241
 24 way AFDD, TPN, type B distritbution board
 125
 24
 EBMAFDD361
 36 way AFDD, TPN, type B distritbution board
 125
 36
    Part No. Description
 EBMAFDDSPDT2
 Surge protection kit for AFDD DB - type 2
 EBMAFDDSPDT12
 Surge protection kit for AFDD DB - type 1&2
   Incomer options
Part No. Description
 EBMAFDDSS
Separation shield - to separate boards mounted on top of each other
 EBMAFDDSP
  Single phasing kit
 EBMAFDDS20
 Multi board alignment spacer - 20mm
  • •
• • •
Incomer devices supplied separately to distribution boards Maximum cable capacity 50mm2
Outgoing AFDD 2-Pole (3 Module)
Arc Fault Detection Device acc. to IEC/EN-62606 Trip types B and C
 Part No.
Description
Rating (A)
Pole configuration
EMS1253N
 Switch Disconnector - 4 pole
 125
 14
 EMS1253
 Switch Disconnector - 3 pole
 125
 24
 EBMAFDDN
 Neutral link kit - required when using 3 pole device
 125
 36
     Fully combined with residual current circuit breaker (RCCB) and miniature circuit breaker (MCB)
Part No.
Description
Rating (A)
Short circuit rating (kA)
Trip type
AFDD-10/2/B/003-A
 10A B 2P 30mA Type A
 10
 10
 B
 AFDD-13/2/B/003-A
13A B 2P 30mA Type A
13
10
B
 AFDD-16/2/B/003-A
 16A B 2P 30mA Type A
 16
 10
 B
 AFDD-20/2/B/003-A
  20A B 2P 30mA Type A
  20
  10
  B
 AFDD-25/2/B/003-A
25A B 2P 30mA Type A
25
10
B
 AFDD-32/2/B/003-A
 32A B 2P 30mA Type A
 32
 6
 B
 AFDD-40/2/B/003-A
 40A B 2P 30mA Type A
 40
 6
 B
 AFDD-10/2/C/003-A
 10A C 2P 30mA Type A
 10
 10
 C
 AFDD-13/2/C/003-A
  13A C 2P 30mA Type A
  13
  10
  C
 AFDD-16/2/C/003-A
16A C 2P 30mA Type A
16
10
C
 AFDD-20/2/C/003-A
 20A C 2P 30mA Type A
 20
 10
 C
 AFDD-25/2/C/003-A
 25A C 2P 30mA Type A
 25
 10
 C
 AFDD-32/2/C/003-A
  32A C 2P 30mA Type A
  32
  6
  C
 AFDD-40/2/C/003-A
 40A C 2P 30mA Type A
 40
 6
 C
