P. 428

                    HEATING & VENTILATION WiFi Control Unit & Electric Boilers
G-Control Hub WiFi Control Unit
The Elnur Gabarron G-Control allows you to connect to your heater from anywhere with an internet connection. Simply wire your G-Control into your internet hub using an RJ45 cable and pair your devices. For pairing your device to a G-Control see your product user manual. For wireless control the G-Control must be connected to an internet connection. The wireless hub allows you to control temperature and programming either through the Elnur App or through the Internet App.
   • Connects via an RJ45 cable
• Connects wirelessly to your
heaters
• Can connect up to 30 heaters
at once
• Temperature control through app
• Timer / Programmer control through app
• Easy set up
• Small sleak design
Part No. Description
    G-CONTROL G-Control Hub WiFi Control Unit
   Electric Combi Boiler 3-15kW Output
Mattira, the new electric boiler range to cover your Domestic Hot Water and Heating needs. Mattira is the ideal option when a totally safe and reliable efficient central heating system
is required. It is the perfect solution for properties with no access to a mains gas supply or homes which have gas boiler restrictions. With this new range of digital electric boilers, GABARRÓN offers you the opportunity to
enjoy the safety and convenience of electricity.
Mattira is the ideal option when a totally safe,
reliable and efficient central heating system
is required. Our digital electric boilers are the
only ones on the market that regulate energy
consumption according to the heating needs
of the installation, taking into account not
only the ambient temperature, but also the
external temperature. Mattira ensures the
optimum comfort in your home, with the maximum running cost savings thanks to its Modulation and AutoHeating Regulation features. The modulating feature of our electric boilers is managed by a Smart Electronic Modulating System (SEM). It applies TRIAC technology combined with an external chrono thermostat to continuously adapt the heating capacity to the heating needs of the premises, thus achieving 100% energy efficiency and overall savings in energy costs. Another feature managed by the SEM System is the Heating Modulation. It is possible to regulate the temperature at which the boiler drives the water heating circuit depending on the outdoor temperature.This method of regulation provides maximum comfort as it anticipates changes in the thermal needs of the house. These features and the fact that, Mattira electric boilers modulate in steps of 1 kW, reduce any possibility of energy waste to the minimum offering you the maximum comfort in your home. These boilers can be installed on single or three-phase electric supplies by using a bridge included with the boiler. All Mattira electric boilers can be limited to any output between 3 and 12 kW on single phase supplies and up to 15 kW on three-phase supplies. None of the Elnur MAC15 boilers emit gases or direct pollution when operating. They do not operate using fuels such as gas or diesel and there is therefore no risk of leaks or explosions.
Electric System Boiler 3-15kw Heat Only
Mattira MAS15, the new electric boiler range to cover your Domestic Heating needs. Mattira is the ideal option when a totally safe and reliable efficient central heating system is required. It
is the perfect solution for properties with no access to a mains gas supply or homes which have gas boiler restrictions. With this new range of digital electric boilers, GABARRÓN offers
you the opportunity to enjoy the safety and
convenience of electricity. Mattira is the ideal
option when a totally safe, reliable and efficient
central heating system is required. Our digital
electric boilers are the only ones on the market
that regulate energy consumption according to
the heating needs of the installation, taking into
account not only the ambient temperature, but
also the external temperature. Mattira ensures
the optimum comfort in your home, with the
maximum running cost savings thanks to its Modulation and AutoHeating Regulation features. The modulating feature of our electric boilers is managed by a Smart Electronic Modulating System (SEM). It applies TRIAC technology combined with an external chrono thermostat to continuously adapt the heating capacity to the heating needs of the premises, thus achieving 100% energy efficiency and overall savings in energy costs. Another feature managed by the SEM System is
the Heating Modulation. It is possible to regulate the temperature at which the boiler drives the water heating circuit depending on the outdoor temperature.This method of regulation provides maximum comfort as it anticipates changes in the thermal needs of the house. These features and the fact that, Mattira electric boilers modulate in steps of 1 kW, reduce any possibility of energy waste to the minimum offering you the maximum comfort in your home. These boilers can be installed on single or three-phase electric supplies by using a bridge included with the boiler. All Mattira electric boilers can be limited to any output between 3 and 12 kW on single phase supplies and up to 15 kW on three-phase supplies. None of the Elnur MAS15 boilers emit gases or direct pollution when operating. They do not operate using fuels such as gas or diesel and there is therefore no risk of leaks or explosions.
      • Each boiler suitable for single or 3-phase supplies
• 3-12kw range rated on single phase supplies
• 3-15kw range rated on 3-phase supplies
• Smart Electronic Modulation System to regulate energy consumption according to exact heating needs at all times (external room stat required)
• Digital modulating which, equates to less energy waste
• Ideal for single bathroom properties
• Up to 12 litres per minute flow rate
• Integral 50ltr store of water with user adjustable temperature regulation to provide “instant” hot water
• S/Steel shielded, Incoloy800 elements for high temperature strength & resistance to corrosion
• Integral expansion vessels, pump & AAV
• Digital display with user adjustable controls and key lock facility
• Wall mounted heating boiler made of insulated steel
• Modulating electronic control of the heater by SEM system (Smart Electronic Modulating System)
• Stainless steel shielded elements INCOLOY 800
• 6L heating expansion vessel • Digital display
• Hydrometer 0-4bar
• Circulating pump
• Auto air vent
• Silent TRIAC power switches • Heating flow detector
• Heating temperature limiter
100oC
• 7 bar heating pressure relief
valve
• Powder coated RAL 9010 steel
structure
• Wall bracket steel template to
set up connections easily
• Compatible with Elnur Connect • Compatible with Underfloor
heating
GENERATE VALUE
Part No.
Output (KW)
Warranty
 Part No.
 Output (KW)
 Dimensions (WxHxD) cm
 Warranty
 Control Type
  MAS15 3 - 15kW 35 x 76 x 26.5 5 Years 24/7 Digital Programmer
     428
Together we
Dimensions (WxHxD) cm
Control Type
     MAC15 3 - 15kW 55.5 x 83 x 45 5 Years 24/7 Digital Programmer
