                    HEATING & VENTILATION
In-Line Duct Fans
Silent MV
Ultra Quiet In-Line Duct Fans
Ultra quiet and low profile helicocentrifugal in-line fans suitable for a wide range of domestic and commercial applications. Fitted with sound absorbent insulation and manufactured with an adjustable two speed 230V 50Hz motor*.
Easy to install and maintain, the SILENT MV fans guarantee exceptional performance with significant noise reduction.
*Except for the SILENT MV 160/100, which is fitted with a patented silent axial motor.
            • Sound absorbent insulation
• 360° rotating connection box
• Sealed for life ball bearings
• Fitted with 2/3 speed motors
• Five year guarantee
• IP44 rated
• Incredibly silent running • High performance
• Significant energy savings • Complies with building
regulations
• Flexible location
• Easy maintenance
      Loosen the Fixing Clamps
Open Clamps on Remove the Both Sides Fan Body
Remove the Terminal Box Lid
Carry out the Wiring of the Unit
Replace the Body & Tighten Clamps
Part No.
Description
Max Airflow l/s (m3/h)
IP Rating
 SILMV160/100S
 Ultra Quiet In-line Fan
 50 (180)
 IP44
 SILMV160/100T*
 Ultra Quiet In-line Fan with Adjustable Timer
 50 (180)
 IP44
 SILMV250/100
 Ultra Quiet In-line Fan
 69 (250)
 IP44
 SILMV250/100T*
  Ultra Quiet In-line Fan with Adjustable Timer
  69 (250)
  IP44
 SILMV350/125
Ultra Quiet In-line Fan
96 (330)
IP44
 SILMV350/125T*
 Ultra Quiet In-line Fan with Adjustable Timer
 96 (330)
 IP44
 SILMV500/150
 Ultra Quiet In-line Fan
 153 (550)
 IP44
 SILMV500/150T*
  Ultra Quiet In-line Fan with Adjustable Timer
  153 (550)
  IP44
 SILMV800/200
Ultra Quiet In-line Fan
253 (910)
IP44
 SILMV800/200T*
 Ultra Quiet In-line Fan with Adjustable Timer
 253 (910)
 IP44
 SILMV1000/200
 Ultra Quiet In-line Fan
 289 (1040)
 IP44
 SILMV1000/200T*
  Ultra Quiet In-line Fan with Adjustable Timer
  289 (1040)
  IP44
 SILMV1300/250
 Ultra Quiet In-line Fan
 353 (1320)
 IP44
     436
Together we
Once Installed, You’ll Never Know it Exists
Innovative Engineering
The SILENT MV has been designed with state of the art technology to achieve results to satisfy the most demanding specifier. The low profile and compact design of the helicocentrifugal fans enable them to be installed where space is restricted, such as false ceilings.
Unique Design
The unique perforated design of the casing directs sound waves into the high density sound absorbent material to prevent air leakage and minimise noise.
Rotating Connection Box
The connection box can be rotated 360° to enable the power cable to be easily connected.
How does it work?
Sound waves produced inside the SILENT MV are directed through
the perforated inner cover and absorbed by the layer of sound absorbent material.
Ease of Maintenance
The central body of the SILENT MV can be easily dismantled from the connections to enable rapid maintenance, without the need to interfere with the ducting.
