                    HEATING & VENTILATION Purge Ventilation
Zehnder AID100
The Zehnder AID100 is an acoustically lined induct 100mm fan. It is ideal for residential applications where the habitable rooms are at risk of overheating, or require purge ventilation due to sealed windows on noise sensitive sites or within a AQMA (Air Quality Management Area).
• Acoustically lined to prevent nuisance running noise when active
• Designed to fit within a ceiling void, cupboard or loft space
• 100% variable speed control via optional SDC1 controller
• Two predefined speeds possible (high / low) using switching by others
without the need for SDC1 controller
• Can be installed in any orientation, horizontal, vertical, on floor, wall
or ceiling
• 4 air changes an hour for rooms up to 13m2 per fan, large rooms can use
multiple fans wired in parallel
   Part No. Description
  AID100
  Acoustic Induct fan, 100mm
 SDC1
 Superduct controller, 1.5 amp
  Zehnder LPID
The Zehnder LPID100 is a low profile induct 100mm fan. It is ideal for residential applications where the habitable rooms are at risk of overheating, or require purge ventilation due to sealed windows on noise sensitive sites or within a AQMA (Air Quality Management Area).
• Designed to fit within a ceiling void, cupboard or loft space
• 100% variable speed control via optional SDC1 controller
• High speed only using switching by others without the need for SDC1
controller
• Can be installed in any orientation, horizontal, vertical, on floor,
wall or ceiling
• 4 air changes an hour for rooms up to 15m2 per fan, large rooms can use
multiple fans wired in parallel
   Part No. Description
  LPID100
  Low profile Induct fan, 100mm
 SDC1
 Superduct controller, 1.5 amp
