443HEATING & VENTILATIONTogether we GENERATE VALUE• For medium to large dwellings and apartments • Suitable for houses up to 285m²• Up to 93% heat recovery efficiency • Down to 0.43 W/l/s SFP• Manual potentiometer or remote digital control with status indication • 4 Airflow modes (100% variable)• Wall and floor mount options• For medium dwellings and apartments• Up to 100 l/s at 160 Pa • Up to 93% heat recovery efficiency• Down to 0.41 W/l/s SFP• Manual potentiometer or remote digital control with status indication • 4 Airflow modes (100% variable)• Wall, ceiling and floor mount options• Reduces condensation• Energy savings• Improved heat distribution• Health benefits• Minimum maintenance• Quiet and efficient• No additional ducting required • Integral, multi-functional controls: 10 fan speeds, automatic heat recovery mode, summer stand-by mode• Easy installation • Up to 10 year filterWhole House Heat Recovery - MVHR / PIV / In-line FansAircycle 3.1Airplus PIVPart No. DescriptionAF 90-AP-STD Airplus LOFT - Positive Input Ventilation SystemAF 90-AP-EHB Airplus LOFT - Positive Input Ventilation System w/ HeaterAircycle 4.1Whole House Heat Recovery MVHRPositive Input Ventilation PIVPart No. Aircycle 3.1 Part No. 3.1 Digital DescriptionAS 90-0301-WINS-01 Aircycle 3.1, Wall Mount, Summer Bypass, Potentiometer PCB, StandardAS 90-0301-WDS-01 Aircycle 3.1, Wall Mount, Summer Bypass, Digital PCB, StandardAM 90-02-301 Aircycle Digital Controller - Required for Digital PCB MVHR UnitsPart No. Aircycle 4.1 Part No. 4.1 Digital DescriptionAS 90-0401-WINS-01 Aircycle 4.1, Wall Mount, Summer Bypass, Potentiometer PCB, StandardAS 90-0401-WDS-01 Aircycle 4.1, Wall Mount, Summer Bypass, Digital PCB StandardAM 90-02-301 Aircycle Digital Controller - Required for Digital PCB MVHR Units• Provides 90% Free Area• Low profile design offers minimal airflow resistance• Available for 204x60 (Single & Double) and 220x90mm (double) Ductwork• Bespoke sleeve configurations available on request• RAL Colour Matching – A2 Rated Polyester Powder Coating• Optional Bezel for non-brick façade• Constructed from 1mm galvanized steelFire Rated AirbricksAirductPart No. DescriptionAF204-09-008 204 x 60mm Single FIREBRICK 400mm L - RAL 9010 (White)AF204-09-003 204 x 60mm Single FIREBRICK 400mm L - RAL 9005 (Black)AF204-09-013 204 x 60mm Single FIREBRICK 400mm L with Bezel - RAL 9010 (White)AF204-09-004 204 x 60mm Single FIREBRICK 400mm L with Bezel - RAL 9005 (Black)AF220-09-001 220 x 90mm Double FIREBRICK 600mm L - RAL 9005 (Black)AF220-09-008 220 x 90mm Double FIREBRICK 600mm L with Bezel - RAL 9010 (White)AF220-09-002 220 x 90mm Double FIREBRICK 600mm L with Bezel - RAL 9005 (Black)*Available in any RAL colour
