Heating & Ventilation515 Together we GENERATE VALUEMVHRs Upright ATMVHRs - Whole House Ventilation With Heat RecoveryPart No. Size (mm) Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%WHHR Midi BY 125 WHHR Midi, Bypass, Universal 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7WHHR Midi LBYH/RBYH 125 Midi, Bypass, Left or Right Drain, Humidistat 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7Midi BY LCD 125 Midi, Bypass, Right Drain, Humidistat 101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7Midi BY+LCDLH/LCDRH 125 Midi, Bypass, Left or Right Drain, Humidistat, Integral LCD101 79 58 36 14 120 69 31 11 2.2 33.9 29.9 26.6 24.6 19.7Midi BY AT 125 Midi, Bypass, Attenuation, Integral LCD 101 79 58 36 14 120 69 31 11 2.2 34 28 21 15 <10Midi BYAT/LH BYAT/RH 125 Midi, Bypass, Attenulation, Left or Right Drain, Humidistat, Integral LCD101 79 58 36 14 120 69 31 11 2.2 34 28 21 15 <10MIDI MVHR with summer bypass & frost-stat, for properties up to 170m2, up to 94% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.50 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit. \ ACOUSTIC ATTENUATIONMAXI MVHR with summer bypass & frost-stat, for properties up to 250m2, up to 92% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.40 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit. \ ACOUSTIC ATTENUATIONMAXI PLUS MVHR with summer bypass & frost-stat, for properties up to 400m2, up to 89% heat exchange efficiency, variable choice of trickle, boost & purge speeds, sfp down to 0.46 W/l/s accurate commissioning via optional integral LCD or remote LCD commissioning unit. \ INTEGRAL ACOUSTIC ATTENUATIONMIDI MAXI MAXI PLUSPart No. Size (mm) Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%WHHRMaxi BY 150 WHHR Maxi , Bypass Universal 177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2WHHRMaxi/ BLHBRH 150 WHHR Maxi, Bypass, Left or Right Drain, Humidistat177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2Maxi BY+LCD 150 Maxi, Bypass, Universal, Integral LCD 177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2Maxi BY+LCDLHLCDRH 150 Maxi, Bypass, Left or Right Drain, Humidistat, Integral LCD177 138 99 60 23 176 97 44 17 4 38.1 35.9 33.2 24.2 20.2Maxi BY-AT 150 Maxi, Bypass, Attenuation Universal, Integral LCD 177 138 99 60 23 176 97 44 17 4 41 38 29 20 <10Maxi BYATH/LH or RH 150 Maxi, Bypass, Attenuation, Left or Right Drain, Humidistat, Integral LCD177 138 99 60 23 176 97 44 17 4 41 38 29 20 <10Part No. Size (mm) Description Airflow l/sec Power - Watts dBA (@ 3m in free field)100% 80% 60% 40% 20% 100% 80% 60% 40% 20% 100% 80% 60% 40% 20%Maxi Plus BY 150 Maxi PLUS , Bypass, Universal 238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus/BLH-BRH 150 WHHR Maxi PLUS , Bypass, Left or Right Drain Humidistat238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus BY LCD 150 Maxi Plus , Bypass, Universal, Integral LCD 238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4Maxi Plus BLHLCD/BRHLCD 150 Maxi Plus, Bypass, Left or Right Drain, Humidistat, Integral LCD238 186 135 84 35 355 184 85 32 8 43.1 37.4 32.8 26 20.4MaxiPlus/ BYAT 150 Maxi Plus, Bypass, Attenuation, Universal, Integral LCD238 186 135 84 35 355 184 85 32 8 47 40 37 26 12MaxiPlus/ ATHLH-ATHRH 150 Maxi, Bypass, Attenulation, Lef or Right Drain, Humidistat Integral LCD238 186 135 84 35 355 184 85 32 8 47 40 37 26 12
