                    TEST INSTRUMENTS Multifunction Testers
12-in-1 MFT with
EV Testing Capability
The complete MFT
kewtech
8-in-1 MFT with
Earth Resistance Test
Industrial MFT with earth resistance
• Continuity - switchable buzzer and auto null • Insulation - 250, 500 & 1000V with voltage
warning LED
• Loop - ATT (low current), high current 0.01 &
0.001 ohm resolution
• Phase to phase loop test & 55V loop test for
CTE transformers
• PSC/PFC - clear indication of what is being
tested
• RCD - Type AC, Type A, selective, auto & ramp • Auto RCD tests with results all on one screen • Phase rotation
• Earth resistance
• Selectable Max Zs tables for MCBs and fuses • PAT testing function with download facility
• Test probe with remote test button
• Polarity Check
KT66DL MFT with KEWEVSE Testing Adapter
6-in-1 MFT with XL
Colour Screen
The commercial MFT with phase rotation
• Continuity - switchable buzzer and auto null • Insulation - 250, 500 & 1000V
• Loop - ATT (low current), high current 0.01 &
0.001 ohm resolution
• Phase to phase loop test & 55V loop test for
CTE transformers
• PSC/PFC - clear indication of what is being
tested
• RCD - Type AC, Type A, selective, auto & ramp • Auto RCD tests with results all on one screen • Phase rotation
• Test probe with remote test button
• Polarity Check
• IP54
EVSE Charge Point Testing Adapter
• Enables testing of EV charging points • PE Pre-test
• PP simulation & CP states A, B, C ,D • CP Error / PE Error / Earth Fault
• LED indication of phases
                   • Continuity - switchable buzzer and auto null (200mA & 15mA)
• Insulation - 250, 500 & 1000V with voltage warning LED
• Two high current loop options: 25A 0.001 Ohm resolution & 6A 0.01 Ohm resolution
• Two low current loop options: 3 wire & 2 wire
• RCD-TestsTypeAC,ACS,A,AS,F,B,BS&EV
• Auto RCD tests with results all on one screen
• Phase rotation
• Earth resistance 3 & 2 wire options
• Surge Protection Device test
• Phase to phase loop test & 55V loop test for CTE
transformers
• PSC/PFC - clear indication of what is being tested
• Selectable Max Zs tables for MCBs and fuses
• UC contact voltage test
• Simultaneous display of L-PE, L-N, N-PE voltage
(TRMS)
• PAT testing function with download facility
• Test probe with remote test button
• Polarity Check
5-in-1 digital MFT with
Magnetic Base
The domestic MFT
• Continuity - switchable buzzer and auto null
• Insulation - 250, 500 & 1000V with voltage
warning LED
• Loop - ATT (low current), high current 0.01
ohm resolution
• PSC/PFC - clear indication of what is being
tested
• RCD - Type AC, Type A, selective, auto & ramp
• Auto RCD tests with results all on one screen
• Polarity Check
• IP54
GENERATE VALUE
• Includes the comprehensive KT66DL multifunction tester with KEWEVSE testing adapter
• Enables testing of EV charging points
Part No. Description
   KT66DL 12-in-1 MFT with EV Testing Capability
  Part No. Description
    KT65DL 8-in-1 MFT with Earth Resistance Test
  Part No. Description
    KT63PLUS 6-in-1 MFT with XL Colour Screen
                 Part No. Description
Part No. Description
  Part No. Description
    KEWEVSE EVSE Charge Point Testing Adapter
        KT63DL 5-in-1 digital MFT with Magnetic Base
KT66EV KT66DL MFT with KEWEVSE Testing Adapter
