                    LIGHTING
Surface Linear
Pace LED Backlit Recessed Panels
 • High performance maintenance free LED panel
• Suitable for installation in offices, educational buildings, retail and healthcare premises
• Slimline design allows for installation into shallow ceiling voids
• TPa as standard
• Powered by Philips
• High performance maintenance free LED panel
• Cool white and warm white options
• White anodised aluminium frame for visual compatibility with ceiling grid
• UGR<19 (unified glare rating) compliant luminaire assisting to eliminate glare for visual comfort
• Cool white, warm white and daylight options
• Self-Test Panel Pod and Sensor Pod compatible
• LED lifespan L80 B10 54,000 hours
• Dimmable and OCTO options available
• Low glare and even light distribution for multiple applications
• Panel Pod emergency option
• Panel Pod sensor option
    Part No. Description Lumens Lm/W CRI CCT
 APACLED1/60/CW
  28W - Cool White
  3300lm
  118lm
  Ra 80
  4000K
 APACLED1/60/WW
 28W - Warm White
 3100lm
 111lm
 Ra 80
 3000K
 APACLED1/60/DL
Endurance
 28W - Daylight
LED Panels
 3250lm
 116lm
 Ra 80
 6500K
     Endurance LED 600x600 Recessed Panel
Supplied with Remote Driver
•
LED lifespan L70 40,000 hours
  Part No. Description Lumens Lm/W CRI CCT
 AERMLED/60/CW
  30W - Cool White
  3001lm
  100lm
  Ra 80
  4000K
 AERMLED/60/WW
 30W - Warm White
 2934lm
 98lm
 Ra 80
 3000K
 AERMLED/60/DL
 30W - Daylight
 3062lm
 102lm
 Ra 80
 6000K
 AERMLED/60
  Endurance LED 1200x300 Recessed Panel
Supplied with Remote Driver
Endurance LED 1200x600 Recessed Panel
AERMLED/30
AERMLED/120
panel pod sensor
  Part No. Description Lumens Lm/W CRI CCT
 AERMLED/30/CW
  30W - Cool White
  3030lm
  101lm
  Ra 80
  4000K
 AERMLED/30/WW
 30W - Warm White
 2835lm
 95lm
 Ra 80
 3000K
 AERMLED/30/DL
 30W - Daylight
 3060lm
 102lm
 Ra 80
 6000K
   Supplied with Remote Driver
Emergency Panel Pod
• Integral emergency pod to convert any new Pace LED and Endurance LED panel to emergency, instantly
• Simple, quick twist and lock fixing
• Supplied with a pre-wired 1m cable
for ease of installation
Emergency Pod Sensor
• Converts Ansell Pace LED and Endurance LED panels to microwave sensor operation
• Provides detection area of 360° with a detection angle of 120°.
GENERATE VALUE
• Total light output of 220lm
• Tri-colour LED shows green for
healthy running condition, red/ flashing for fault conditions and white for emergency operation
• Simple twist and lock connection • Pre-wired 300mm 4-core flex for
easy installation
• Fast and efficient installation.
• Adjustable time delay and distance
panel pod emergency
  Part No. Description Lumens Lm/W CRI CCT
 AERMLED/120/CW
  60W - Cool White
  5245lm
  87lm
  Ra 80
  4000K
 AERMLED/120/WW
 60W - Warm White
 5194lm
 87lm
 Ra 80
 3000K
 AERMLED/120/DL
 60W - Daylight
 5250lm
 86lm
 Ra 80
 6000K
     Part No. Description
  AIRMLED/POD/3NM/ST
  Panel Pod Emergency - 5W Cool White
 AIRMLED/POD/MWS
 Emergency Pod Sensor - 1W Microwave Sensor
