P. 551

                    LIGHTING
Downlights
Prism Pro
Prism Pro OCTO WiZ Connected FRD 8W Tunable White
Edge GU10 Fire Rated Downlight
   Supplied Less Lamp
    • 220-240V IP65 LED WiZ enabled tunable white Fire Rated Downlight
• Supplied with matt white bezel as standard
• Tunable between 2700K - 6500K via Wiz App and voice control
• Remote driver with 2x1.5mm2 +
CPC loop-in, loop-out colour coded push fit piano terminals provide an easy and efficient installation
• Detachable LED driver for fast fix install
Prism Pro Anti-glare
Prism Pro CCT Anti-Glare FRD 7W
• Low profile design and remote driver allow installation into shallow ceilling voids
• Fully tested for 30, 60 and 90 minute ceiling types to meet Part B of Building Regulations
• Fully tested to meet Part C (moisture), Part E (acoustic) and Part L (energy) of Building Regulations
• Wide 60° beam angle for increased light distribution
• LED lifespan L70 60,000 hours
• Remote driver with 2x1.5mm2 + CPC loop-in, loop-out colour coded push fit piano terminals provide an easy and efficient installation
• Detachable LED driver for fast fix install
• Low profile design and remote driver allow installation into shallow ceilling voids
• Fully tested to meet Part C (moisture), Part E (acoustic) and Part L (energy efficiency) of Building Regulations
• Suitable for standard GU10 halogen or LED lamps
• Protective sheathing spring clips for ease of installation and ceiling protection
• Push fit terminals for fast loop-in, loop-out wiring
• Twistlock lamp retaining ring for ease of lamp replacement
• Ultra-slim bezel profile
• Compact Fire Rated downlight for
shallow ceiling voids
iCage Mini 50W GU10 Die-Cast Downlight
edge GU10 frd
Part No. Description
  AEFRD/MW
  50W - Matt White
 AEFRD/CH
 50W - Chrome
 AEFRD/SC
 50W - Satin Chrome
    Part No. Lumens Lm/W CRI CCT
  APRILEDP/OCTOW
  573lm (2700K) - 547lm (6000K)
  82lm (2700K) - 78lm (6000K)
  Ra 80
  Tunable White
    Supplied Less Lamp
     cage
mini
• 220-240V IP65 LED dimmable CCT fire rated architectural downlight
• Anti-glare design to create visual
comfort
• Supplied with matt white bezel
as standard
• Chrome, satin chrome and matt
black bezels sold separately
• Integrated switch allows installer the choice of 2700K, 3000K, 4000K
or 6000K colour temperature options
GENERATE VALUE
• Suitable for standard GU10 LED or halogen lamps retrofit
• Protective polycarbonate spring clip covers for ceiling protection and ease of installation
• Dedicated forward heat lamps NOT required
• Extra large terminals for fast loop-in, loop-out wiring
• Twistlock lamp retaining ring for ease of lamp replacement
• Ultra-slim bezel profile
• Compact Fire Rated downlight for
shallow ceiling voids
Part No. Description
  AMICD/W
 50W - White
 AMICD/MW
  50W - Matt White
 AMICD/BR
50W - Brass
 AMICD/CH
 50W - Chrome
 AMICD/SC
 50W - Satin Chrome
 AMICD/AB
  50W - Antique Brass
 AMICD/BLC
 50W - Black Chrome
   • LED Lifespan L70 60,000 hours Part No. Lumens Lm/W CRI CCT
   APRILEDP/AG/CCT
  460lm (2700K) - 515lm (6000K)
  66lm (2700K) - 74lm (6000K)
  Ra 80
  Tunable White
   Together we
