Page 554 - Fegime - Electrical Product Guide Issue 1 V5
P. 554

                    LIGHTING
LED Downlights
Comfort LED Downlight
Supplied with Remote Driver
• Economic high performance IP44 downlight
• Deep cut-off angle for glare control and comfort
• Osram LED technology and enhanced diffuser design for outstanding uniformity
• Downlight design allows
  installation into existing hole-cut
outs from 200mm to 220mm
• Polycarbonate housing with
unique thermal management for
durability and optimum lifespan
• LED lifespan L70 50,000 hours
• Dimmable and Emergency options
   Part No. Description Lumens Lm/W CRI CCT
 ACOLED1/CW
  21W - Cool White
  2070lm
  99lm
  Ra 80
  4000K
 ACOLED2/CW
 29W - Cool White
 2121lm
 73lm
 Ra 80
 4000K
 ACOLED1/WW
 21W - Warm White
 1666lm
 80lm
 Ra 80
 3000K
 ACOLED2/WW
 29W - Warm White
 2114lm
 73lm
 Ra 80
 3000K
  Options
Part No. Description
  /M3
 Emergency
 /DD
  Digital Dimming
 DD/M3
 Digital Dimming Emergency
   Galaxy CCT LED Downlight
 Supplied with Remote Driver
• Compact IP65 LED Downlight which out performs twin 18W and 26W PLC lamp variants
• One product provides both 3000K and 4000K colour temperature options
• Identical cut-out dimensions to replace Galaxy PLC
• Fitting and driver pre-wired with ST18 connectors
Options
• Faceted reflector and optical fresnel lens provides outstanding performance, uniformity and glare control
• Removable twist on, twist off bezel provides option of utilising alternative bezel and drop glass accessories
• Dimmable and Emergency options • LED lifespan L70 50,000 hours
    Part No. Description Lumens Lm/W CRI CCT
 AGALED/1/CCT
  15W - Cool/ Warm White
  1557lm/ 1484lm
  103lm/ 98lm
  Ra 80
  4000K/ 3000K
 AGALED/2/CCT
 20W - Cool/ Warm White
 2250lm/ 2230lm
 112lm/ 112lm
 Ra 80
 4000K/ 3000K
  Part No. Description
  /M3
  Emergency
 /DD
 Digital Dimming
 DD/M3
 Digital Dimming Emergency
    554
Shown with optional drop glass
