                    LIGHTING Downlights
LED Fixed/Adjustable/Baffle Fire Rated Downlights
mpro
LEDchroicTM lens provides halogen appearance with LED efficiency, anti-glare and precise beam control
aurora lighting
aone control
works with .control
    • Unique convertible design to fit ceiling voids as shallow as 53mm
• Insulation coverable
• Patented fire rated downlight
with intumescent
• Interchangeable IP65 bezel for
fixed version
• IP65 rated for adjustable and baffle option
• FastRFixTM rapid install system connector included
• Tested in 30, 60 and 90 minute solid timber joist, plus 30 minute i-joist and open web joist fire rated ceilings††
Triac Inline Dimmer Smart Rotary Dimmer
   120W 320W
 AIR leakage (excluding adjustable)
30, 60, 90 minutes
(Solid Timber Joists)
30 minutes
(I-Joists & Metal Web Joists)
 mPROTM Triac Dimmable Fixed (IP65 when used with IP65 Bezel)
H
 Part No. Watts Colour Lumens lm/W Beam Cutout (ø)
  AU-MPRO1A/27
 6W
 2700K
 560lm
 93
 60o
 70mm
 AU-MPRO1A/30
  6W
  3000K
  600lm
  100
  60o
  70mm
 AU-MPRO1A/40
 6W
 4000K
 640lm
 107
 60o
 70mm
  Bezel Options
†Add suffix W, MW, PC, SN or BLK for White, Matt White, Polished Chrome, Satin Nickel or Black finishes.
* Add suffix W, MW, PC or SN for White, Matt White, Polished Chrome or Satin Nickel finishes.
AU-MPRO1A
(H) 100mm Height (OD) 88mm Overall (Ø)
Part No. Description
  AU-BZ600†
 mProTM Fixed IP65 Aluminium Downlight Bezel
 AU-AP600*
 mProTM Fixed Fire Rated Aluminium Adaptor Plate
 AU-BZ605W
  mProTM Fixed Slimtrim Aluminium Baffle Bezel
 AU-MPROTL**
 mProTM Fixed Trimless Aluminium Bezel
  ** Add suffix W or BLK for White or Black finishes.
3 hour Emergency pack AU-FRLM10EM available.
†† Suitable for use in 30 minute i-joist fire rated ceilings. 7 Year Warranty
  Conservation of Fuel and Power
compliant
 Conservation of Fuel and Power
compliant
 Floating earth termination for earth continuity
Push fit
Loop in/Loop out terminals
Convertible design for shallow ceiling voids
Comes with FastRFixTM connector for fast installation
             Twist&LockTM Fixed IP Rated Bezels
White
Matt White
Polished Chrome
Satin Nickel
  Adaptor Plate
Trimless
Slim Trim
