P. 564

                     LIGHTING
GU10 Professional Fixed/Adjustable Fire Rated Downlights
 Downlights
   efd pro
Push Fit Terminal Block for Faster,TOOL FREE Installation
 • EN-FD101 - Fixed
• EN-FD102 - Adjustable up to 28
• EN-FD103 - Fixed IP65 rated
• Loop in / loop out terminal block
for quick and easy installation
Fixed/IP65
Adjustable
Bezel Options
* Add suffix W, MW, PC or SN for White, Matt White, Polished Chrome or Satin Nickel finishes.
3 Year Warranty
Connector with push fit
loop in/loop out terminals suitable for use with solid or stranded cable
GU10 Compact Fire Rated Downlights
• Tested in 30, 60 and 90 minute solid timber joist fire rated ceilings
   AIR leakage (excluding adjustable)
works with .light
Smart Tuneable GU10
Dimmable Standard GU10 PLUS Triac Inline Dimmer
OR Smart Rotary Dimmer
Non-Dimmable Standard GU10 PLUS On/Off Relay
Products in this range pass fire testing with I-Joists, metal web joists and solid timber joists.
   Part No. Input Horz. Adj. Cutout (ø)
   EN-DLM981X 240V - 75mm
   120W 320W
  Part No. Input Horz. Adj. Cutout (ø)
   EN-DLM982X 240V 20o 85mm
   Part No. Description
  EN-BZ91*
 EFDTM PRO 90mm Fixed Aluminium Downlight Bezel
 EN-BZ92*
  EFDTM PRO 102mm Adjustable Aluminium Downlight Bezel
 EN-BZ93*
 EFDTM PRO 90mm IP65 Aluminium Downlight Bezel
  EN-DLM981X
(H) 107mm Height (OD) 90mm Overall (Ø)
EN-DLM982X
(H) 120mm Height
(OD) 102mm Overall (Ø)
H
    Insulation coverable 300mm fibre based
OD
     INSULATION
FREE AIR
• •
No accessory required
No insulation cut-out required
    efd
• Pressed steel body with aluminium bezel
• EN-FD101 - Fixed
• EN-FD102 - Adjustable up
to 28
• EN-FD103 - Fixed IP65 rated
Fixed/IP65
Adjustable
3 Year Warranty
• Loop in / loop out terminal block for quick and easy installation
• Tested in 30, 60 and 90 minute solid timber joist fire rated ceilings
AIR leakage (excluding adjustable)
IP65
H
      Part No. Input Horz. Adj. Cutout (ø)
  EN-FD101W
 240V
 -
 75mm
 EN-FD101PC
  240V
  -
  75mm
 EN-FD101SN
 240V
 -
 75mm
  OD
  Fixed
Adjustable
Fixed IP65
(H) 125mm Height (OD) 87mm Overall (Ø)
EN-FD102
(H) 30mm Height
(OD) 100mm Overall (Ø)
EN-FD103
(H) 130mm Height (OD) 86mm Overall (Ø)
GENERATE VALUE
EN-FD101
Part No. Input Horz. Adj. Cutout (ø)
  EN-DLM982X
 240V
 28o
 85mm
 EN-FD102PC
  240V
  28o
  85mm
 EN-FD102SN
 240V
 28o
 85mm
  Part No. Input Horz. Adj. Cutout (ø)
  EN-DLM982X
 240V
 -
 75mm
 EN-FD103PC
  240V
  -
  75mm
 EN-FD103SN
 240V
 -
 75mm
     564
