P. 567

                    LIGHTING
Downlights
High Power Integrated Polycarbonate LED Downlights
   unifit uni-fit
• ThermoTecTM heat management technology
• Suitable for all new and retrofit installation requirements
• Pre-wired with 500mm 2 core cable
Non-Dimmable
Triac Dimmable
3 Year Warranty
• IP44 rated
• Supplied with integrated
LED driver
TP(b)
Triac Inline Dimmer
Smart Rotary Dimmer
On/Off Relay
 works with .control
   120W 320W
 Part No. Watts Colour Lumens lm/W Beam Cutout (ø)
  EN-DL10/30
 10W
 3000K
 1100lm
 110
 100o
 90mm
 EN-DL10/40
 10W
 4000K
 1100lm
 110
 100o
 90mm
 EN-DL15/30
  15W
  3000K
  1650lm
  110
  100o
  120mm
 EN-DL15/40
15W
4000K
1650lm
110
100o
120mm
 EN-DL23/30
 23W
 3000K
 2530lm
 110
 100o
 170mm
 EN-DL23/40
 23W
 4000K
 2530lm
 110
 100o
 170mm
 EN-DL30/30
  30W
  3000K
  3300lm
  110
  100o
  200mm
 EN-DL30/40
 30W
 4000K
 3300lm
 110
 100o
 200mm
    H
   OD
(H) 60mm Height
(OD) 120mm Overall (Ø)
EN-DDL15
(H) 60mm Height
(OD) 150mm Overall (Ø)
EN-DDL20
(H) 65mm Height
(OD) 200mm Overall (Ø)
EN-DDL25
(H) 65mm Height
(OD) 235mm Overall (Ø)
  Part No. Watts Colour Lumens lm/W Beam Cutout (ø)
  EN-DDL10/40
 10W
 4000K
 820lm
 82
 100o
 90mm
 EN-DDL15/40
  15W
  4000K
  1200lm
  80
  100o
  90mm
 EN-DDL20/40
 20W
 4000K
 1800lm
 90
 100o
 120mm
 EN-DDL25/40
 25W
 4000K
 2000lm
 80
 100o
 120mm
   High Performance Aluminium LED Downlights
(H) 60mm Height
(OD) 120mm Overall (Ø)
EN-DL15
(H) 60mm Height
(OD) 150mm Overall (Ø)
EN-DL23
(H) 65mm Height
(OD) 200mm Overall (Ø)
EN-DL30
(H) 65mm Height
(OD) 235mm Overall (Ø)
TP(b)
Triac Inline Dimmer
1-10V Inline Dimmer
Smart Rotary Dimmer
EN-DDL10
EN-DL10
   lumi-fit lumifit
• Low cost energy saving alternative to compact fluorescent fittings
• Delivering up to 108lm/W
• Opal diffuser for even
light distribution
Triac Dimmable
Emergency Pack
• IP54 rated
• Supplied with remote
triac dimmable constant current LED driver
works with .control
    Part No. Watts Colour Lumens lm/W Beam Cutout (ø)
  EN-DDLH413*/40
 13W
 4000K
 1260lm
 97
 100o
 120mm
 EN-DDLH618*/40
 18W
 4000K
 1800lm
 100
 100o
 160mm
 EN-DDLH818*/40
  18W
  4000K
  1900lm
  106
  100o
  200mm
 EN-DDLH825*/40
25W
4000K
2600lm
104
100o
200mm
 EN-DDLH840*/40
  40W
  4000K
  4320lm
  108
  100o
  200mm
 EN-DDLH1045*/40
 45W
 4000K
 4500lm
 100
 100o
 230mm
    1-10V
   OD
(H) 45mm Height
(OD) 145mm Overall (Ø)
EN-DDLH618
(H) 45mm Height
(OD) 190mm Overall (Ø)
EN-DDLH818
(H) 45mm Height
(OD) 228mm Overall (Ø)
H
EN-DDLH825
  * Add suffix DA for DALI or V for 1-10V dimmable option (note DALI Emergency - the EM side will not report back) 3 Year Warranty
GENERATE VALUE
567
EN-DDLH413
(H) 45mm Height
(OD) 228mm Overall (Ø)
EN-DDLH840
(H) 45mm Height
(OD) 228mm Overall (Ø)
EN-DDLH1045
(H) 54mm Height
(OD) 280mm Overall (Ø)
Part No. Description
   EN-PLEM2 3 Hour Maintained Emergency Pack
   Conservation of Fuel and Power
compliant
 Conservation of Fuel and Power
compliant
