P. 569

                    LIGHTING
Surface Mounted Linears
IP65 LED Anti-Corrosives
   linearpac
• Designed to directly replace single or twin lamp fluorescent fittings in size and output
• Over 50% energy savings compared to traditional fluorescent
• Clip in gear tray for ease of installation and maintenance
• Fully polycarbonate diffuser and base (6ft base is ABS)
Single
Twin
• IP65 rated
• 2x IP65 rated cable glands
supplied
• IK08 rated impact resistance
• 20mm conduit entry at both ends
and at the rear
• Delivering up to 111lm/W
• Stainless steel anti-tamper clips
• -20 to 40 ambient operating
temperature
  Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-ANT1217B*/40
 Non-Dim
 17W
 4000K
 2400lm
 141
 1 x 36W
 4
 EN-ANT1525B*/40
  Non-Dim
  25W
  4000K
  3600lm
  144
  1 x 36W
  4
 EN-ANT1834B*/40
 Non-Dim
 33W
 4000K
 4200lm
 124
 1 x 58W
 5
  On/Off Relay
L
(L) 1270mm Length (W) 85mm Width (H) 80mm Height
EN-ANT1525B
(L) 1570mm Length (W) 85mm Width (H) 80mm Height
works with .control
EN-ANT1558B
(L) 1570mm Length (W) 118mm Width (H) 80mm Height
EN-ANT1869B
(L) 1870mm Length (W) 118mm Width (H) 80mm Height
     Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-ANT1240B†/40
 Non-Dim
 40W
 4000K
 4560lm
 114
 1 x 36W
 4
 EN-ANT1558B†/40
  Non-Dim
  58W
  4000K
  7200lm
  124
  1 x 36W
  4
 EN-ANT1869B†/40
 Non-Dim
 69W
 4000K
 8400lm
 121
 1 x 58W
 5
    H
EN-ANT1217B
W
EN-ANT1834B
(L) 1870mm Length (W) 85mm Width (H) 80mm Height
EN-ANT1240B
(L) 1270mm Length (W) 118mm Width (H) 80mm Height
 *Add suffix EM for Emergency option.
†Add suffix EM or MS for Emergency or Microwave Sensor options. 5 Year Warranty
Surface Mounted LED Linear
    princetonpro
• Up to 50% savings compared to fluorescent fittings
• Steel housing and high quality polycarbonate diffuser
• Delivering 110lm/W
• IK06 rated impact resistance
Single
Twin
• Standard version fitted with push-fit terminal block for even faster installation
• Multiple BESA mounting points (matches traditional fluorescent)
Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-SF1220*/40
 Non-Dim
 20W
 4000K
 2200lm
 110
 110o
 4
 EN-SF1530*/40
  Non-Dim
  30W
  4000K
  3300lm
  110
  110o
  5
 EN-SF1840*/40
 Non-Dim
 40W
 4000K
 4400lm
 110
 110o
 6
       L
Single & Twin 1200mm
(L) 1188mm Length (W) 208mm Width (H) 70mm Height
Single & Twin 1500mm
(L) 1488mm Length (W) 208mm Width (H) 70mm Height
Single 1800mm
(L) 1788mm Length (W) 208mm Width (H) 70mm Height
H
W
  works with .control
  Part No.
Type
Watts
Colour
Lumens
lm/W
T8 Subst.
Length (ft)
 EN-SF1240*/40
  Non-Dim
  40W
  4000K
  4400lm
  110
  110o
  4
 EN-SF1560*/40
 Non-Dim
 60W
 4000K
 6600lm
 110
 110o
 5
    *Add suffix EM for Emergency, DA for DALI or V for 1-10V dimmable options 5 Year Warranty
GENERATE VALUE
569
1-10V Inline Dimmer
Smart Rotary Dimmer
1-10V
   Together we
Conservation of Fuel and Power
compliant
Conservation of Fuel and Power
compliant
