P. 570

                    LIGHTING
Panels
LED Edge-Lit Flat Panels
   edgelitepro
• Over 60% energy savings compared to traditional fluorescent
• Edge-lit panel for complete uniformity across diffuser
• High quality light guide designed to prevent yellowing
600 x 600mm
1200 x 600mm 1200 x 300mm Accessories
• Delivering 110lm/W
• SDCM <4 providing consistent
light colour quality
• UGR19 (Unified Glare Rating)
• IP44 rated from the front
• Suitable for installation in 15 &
24mm T-bar ceilings
 Part No. Type Watts Colour Lumens lm/W Beam
  EN-FPRO6060B*/40†
  Non-Dim
  30W
  4000K
  3300lm
  110
  110o
 EN-FPRO6060B*/50†
 Non-Dim
 30W
 5000K
 3300lm
 110
 110o
     H
TP(b)
   WL
EN-FP6060C
(L) 595mm Length (W) 595mm Width (H) 10mm Height
EN-FP1260C
(L) 1195mm Length (W) 595mm Width (H) 10mm Height
EN-FP1230C
(L) 1195mm Length (W) 295mm Width (H) 10mm Height
works with .control
On/Off Relay
1-10V Inline Dimmer
    Part No. Type Watts Colour Lumens lm/W Beam
  EN-FPRO1260B*/40†
  Non-Dim
  50W
  4000K
  5500lm
  110
  110o
 EN-FPRO1260B*/50†
 Non-Dim
 50W
 5000K
 5500lm
 110
 110o
      Part No. Type Watts Colour Lumens lm/W Beam
  EN-FPRO1230B*/40†
  Non-Dim
  30W
  4000K
  3300lm
  110
  110o
 EN-FPRO1230B*/50†
 Non-Dim
 30W
 5000K
 3300lm
 110
 110o
     1-10V
Part No. Description
   EN-LPEM2 3 Hour Emergency Pack for Panel Range
  *Add suffix DA for DALI or V for 1-10V dimmable option †For DALI Emergency - the EM side will not report back 5 Year Warranty
LED Backlit Flat Panels 600 x 600mm
 Conservation of Fuel and Power
compliant
   backlite
• Flicker free driver
• Delivering 100lm/W
• No light guide, removing the risk
of yellowing
• Life not affected by frequent
switching e.g. when used with occupancy controls
600 x 600mm Accessories
5 Year Warranty
• Suitable for installation in 15 & 24mm T-bar ceilings
• Power Factor >0.9 • Slim 33mm height
  H
TP(b)
 Part No. Type Watts Colour Lumens lm/W Beam
  EN-BLP6060/40
  Non-Dim
  36W
  4000K
  3600lm
  110
  110o
 EN-BLP6060/50
 Non-Dim
 36W
 5000K
 3600lm
 110
 110o
   L
EN-BLP6060
(L) 595mm Length (W) 595mm Width (H) 33mm Height
W
      Part No. Description
   EN-LPEM2 3 Hour Emergency Pack for Panel Range
    570
works with .control
On/Off Relay
GENERATE VALUE
Conservation of Fuel and Power
compliant
 Together we
   E
E
D
D
FPRO1230 FPRO6060
R
R
A
A
T
